Arsenogorceixite

BaAl3(AsO4)(AsO3OH)(OH)6
IMA status
  • Approved
IMA symbol
Agcx
Discovered
1991
Also known as
  • Arséenogorceixite
  • Arsenogorceixiet
  • Arsenogorceixitt
  • +4 more

Where it forms, where it's found

Geological setting

Oxidized veins of hydrothermal polymetallic deposit.

Oxidized veins of hydrothermal polymetallic deposit

Type locality
Clara Mine
  1. Oberwolfach
  2. Ortenaukreis
  3. Freiburg Region
  4. Baden-Württemberg
  5. Germany

48.3797°, 8.2289°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous.
Transparency
Transparent · Translucent
Colour
White · yellowish white · yellow · greenish yellow · greenish · pale blue · colourless.
Streak
White.
Tenacity
brittle
Cleavage
None Observed

Probably (0001) perfect as in other members of the group.

Fracture
Conchoidal
Density
3.655 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.645
Surface relief
Moderate
Principal indices
nω 1.645 · nε 1.645
Birefringence
0.000
Pleochroism
Non-pleochroic
Extinction
Parallel
Luminescence
None
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]0 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation0 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 7.103 Å · c = 17.394 Å
Z
3
Morphology

Tabular crystals, flattened on (0001), as pseudooctahedral crystals showing (1011) and (0001), and as spherulitic aggregates of radiating crystals.

Type-locality form

Minute rhombohedral crystals in crusts and aggregates.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
37.38%
33AsArsenicArsenic274.922149.844
25.01%
56BaBariumBarium1137.327137.327
22.92%
13AlAluminiumAluminium326.98280.946
13.51%
1HHydrogenHydrogen71.0087.056
1.18%
Total599.159100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Arséenogorceixite
  • Arsenogorceixiet
  • Arsenogorceixitt
  • IMA1989-055
  • Sulfat-freier Weilerit
  • Sulfate-free weilerite
  • Sulphate-free weilerite

In other languages

German
Arsenogorceixit · IMA 1989-055
Italian
arsenogorceixite

Classification

Strunz
10th ed.

8.BL.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.10ArsenogorceixiteSpecies
Dana
8th ed.

43.04.01.09

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.01Beudantite GroupGroup
  • 43.04.01.09ArsenogorceixiteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1981Walenta, K. (1981) Mineralien der Beudantit-Crandallitgruppe aus dem Schwarzwald: Arsenocrandallit und sulfatfreier Weilerit. Schweizerische Mineralogische und Petrographische Mitteilungen, 61, 23-35.
  2. 1991Schwab, R.G., Götz, C., Herold, H., Pinto de Oliveira, N. (1991) Compounds of the crandallite type: Synthesis and properties of pure (Ca, Sr, Ba, Pb, La, Ce to Eu) - arsenocrandallites. Neues Jahrbuch für Mineralogie, Monatshefte: 1991: 97-112.
  3. 1993Walenta, K., Dunn, P.J. (1993) Arsenogorceixite von der Grube Clara im mittleren Schwarzwald (Arsenogorceixite from the Clara mine, central Black Forest). Aufschluss: 44: 250-254. [in German]
  4. 1996Jambor, John L., Pertsev, Nikolai N., Roberts, Andrew C. (1996) New mineral names. American Mineralogist, 81. 249-254
  5. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
