Hammarite

Cu2Pb2Bi4S9
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hmr
Discovered
1924
Also known as
  • Hammariet

Where it forms, where it's found

Geological setting

Hydrothermal veins.

Hydrothermal veins

Type locality
Gladhammar mines
  1. Västervik
  2. Kalmar County
  3. Sweden

57.7194°, 16.4250°

50recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Steel-grey with red tint
Streak
Black
Cleavage
Distinct/Good

(010) good.

Fracture
Conchoidal
Density
6.734 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(39.7,43.6) 400, (39.8,43.7) 420, (39.8,43.8) 440, (39.9,44.0) 460, (40.1,44.1) 480, (40.3,44.4) 500, (40.2,44.6) 520, (40.1,44.6) 540, (40.0,44.7) 560, (39.9,44.7) 580, (39.8,44.6) 600, (39.6,44.4) 620, (39.4,44.1) 640, (39.1,43.7) 660, (38.8,43.3) 680, (38.6,42.9) 700
Reflected-light panel
39.7 %anisotropic · dual curve
Specimen sRGB 224, 157, 87
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 33.772 Å · b = 11.5857 Å · c = 4.01 Å
Ratio a:b:c
1 : 0.343 : 0.119
Z
4
Morphology

Short prisms; needle-like.

Type-locality form

Short prisms or needles on quartz.

Comment

SG Pbnm or Pbn21

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth4208.980835.920
50.18%
82PbLeadLead2207.200414.400
24.87%
16SSulfurSulfur932.060288.540
17.32%
29CuCopperCopper263.546127.092
7.63%
Total1665.952100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hammariet

In other languages

German
Hammarit
Italian
Hammarite

Classification

Strunz
10th ed.

2.HB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HBWith Cu, Ag, Fe, Sn and PbGroup
  • 2.HB.05aHammariteSpecies
Dana
8th ed.

03.04.05.04

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.05Aikinite Group (Orthorhombic containing Pb, Cu, Bi, & S)Group
  • 03.04.05.04HammariteSpecies
CIM

5.7.7

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.7HammariteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1924Johansson, K. (1924) Bidrag till Gladhammar-gruvornas mineralogi [Contribution to the mineralogy of the Gladhammar mines]. Arkiv für Kemi, Mineralogi och Geologi [Archive for Chemistry, Mineralogy and Geology], 9 (8) 1-22
  2. 1925Foshag, W.F. (1925) New minerals: new species. American Mineralogist: 10: 157-158.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1970Fleischer, M. (1970) New mineral names. American Mineralogist, 55 (3-4). 533-535
  5. 1976Mumme, William G., Welin, Eric, Weunsch, B. J. (1976) Crystal chemistry and proposed nomenclature for sulfosalts intermediate in the system bismuthinite-aikinite (Bi2S3-CuPbBiS3). American Mineralogist, 61 (1-2). 15-20
