Haüyne

Na3Ca(Si3Al3)O12(SO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hyn
Also known as

Where it forms, where it's found

Geological setting

Alkaline volcanics

In phonolites and other silica deficient alkaline igneous rocks. Also in some skarns ( possibly metaevaporites).

Type locality
Mount Somma
  1. Metropolitan City of Naples
  2. Campania
  3. Italy
205recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous to greasy.
Transparency
Transparent · Translucent · Opaque
Colour
Blue · white · grey · yellow · green · pink

The various colours arise from minor cage contents

Streak
Very pale blue to white. Lazurite variety is bright blue
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (110)

Fracture
Irregular/Uneven
Density
2.44 g/cm³

Optical

Optical type
Isotropic
Surface relief
Moderate
Principal indices
n 1.494 – 1.509
Pleochroism
Non-pleochroic
Luminescence
Nonfluorescent
UV response
Reddish orange to purplish pink in LW
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.502

Crystallography

Crystal system
Isometric
Space group
#212
Cell parameters
a = 9.11(2) Å
Morphology

Dodecahedral or octahedral

Twinning

On (111)

Comment

Range: 9.08-9.13

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
45.52%
14SiSiliconSilicon328.08584.255
14.98%
13AlAluminiumAluminium326.98280.946
14.40%
11NaSodiumSodium322.99068.970
12.27%
20CaCalciumCalcium140.07840.078
7.13%
16SSulfurSulfur132.06032.060
5.70%
Total562.293100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • K

Synonyms

  • Ajuin
  • Auina
  • Ittnerit
  • Latialit
  • Marialite (of Ryllo)
  • Scolopsit
  • Skolopsit

In other languages

French
Amphigène octaédrique · haüyne · Hauynite · Pléonaste blanc
German
Haüyn · Hauynit
Spanish
Haüyna
Italian
Haüyna · Haüyne · Hauynite
Portuguese
Hauyna · Hauynita · Hauynite
Japanese
アウイナイト · アウイン · らんぽうせき · 藍宝石 · 藍方石
Chinese
蓝方石 · 藍方石
Russian
Гаюин
Arabic
هاوين

Classification

Strunz
10th ed.

9.FB.10

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FBTektosilicates with additional anionsGroup
  • 9.FB.10HaüyneSpecies
Dana
8th ed.

76.02.03.03

  • 76Tectosilicates Al-si FrameworkClass
  • 76.02Al-Si Framework Feldspathoids and related speciesType
  • 76.02.03Sodalite groupGroup
  • 76.02.03.03HaüyneSpecies
CIM

17.10.4

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.4HaüyneSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1807Bruun-Neergard, T.C. (1807) De de la Haüyne, Nouvelle substance minérale. Journal des Mines, 21, premier semestre 1807, 365-380
  2. 1807Bruun-Neergard, T.C. (1807 b) Ueber den Hauyn (la Hauyne), eine neue mineralische Substanz. Journal für die Chemie, Physik und Mineralogie, 4, 417-429.
  3. 1963VanPeteghem, J. K.; Burley, B. J. (1963) Studies on solid solution between sodalite, nosean and hauyne. The Canadian Mineralogist, 7 (5). 808-813
  4. 1985Tsuchiya, Norihiko; Takéuchi, Yoshio (1985) Fine texture of hauyne having a modulated structure. Zeitschrift für Kristallographie, 173 (3-4). 273-281 doi:10.1524/zkri.1985.173.3-4.273DOI: 10.1524/zkri.1985.173.3-4.273
  5. 1991Hassan, I. and Grundy, H.D. (1991) The crystal structure of hauyne at 293 and 153 K. Canadian Mineralogist, 29, 123-130.
