Hennomartinite

SrMn3+2(Si2O7)(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Hma
Discovered
1992
Also known as
  • Hennomartiniet
  • IMA1992-033

Where it forms, where it's found

Geological setting

Hydrothermal reaction product of primary manganese ore.

Type locality
Wessels Mine
  1. Joe Morolong Local Municipality
  2. John Taolo Gaetsewe District Municipality
  3. Northern Cape
  4. South Africa

-27.1135°, 22.8544°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Yellow-brown
Cleavage
None Observed
Density
3.68 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 63°
Refractive index
1.82
Surface relief
Very high
Principal indices
nα 1.82
Pleochroism
Strong

yellowish brown to dark red brown

Dispersion
small
UV response
Not fluorescent.

Crystallography

Crystal system
Orthorhombic
Space group
Cmcm
Cell parameters
a = 6.245(1) Å · b = 9.031(2) Å · c = 13.404(2) Å
Ratio a:b:c
1 : 1.446 : 2.146
Z
4
Parting
none
Type-locality form

Yellow-brown poikioblasts to 1 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
38.30%
25MnManganeseManganese254.938109.876
26.31%
38SrStrontiumStrontium187.62087.620
20.98%
14SiSiliconSilicon228.08556.170
13.45%
1HHydrogenHydrogen41.0084.032
0.96%
Total417.688100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ca
  • Ba

Synonyms

  • Hennomartiniet
  • IMA1992-033

In other languages

German
Hennomartinit · IMA 1992-033
Italian
Hennomartinite
Chinese
亨诺马丁石

Classification

Strunz
10th ed.

9.BE.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.05HennomartiniteSpecies
Dana
8th ed.

56.02.03.02

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.03Lawsonite - Ilvaite groupGroup
  • 56.02.03.02HennomartiniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1992Armbruster, Thomas, Oberhänsli, Roland, Bermanec, Vladimir (1992) Crystal structure of SrMn2[Si2O7](OH)2·H2O, a new mineral of the lawsonite type. European Journal of Mineralogy, 4 (1) 17-22 doi:10.1127/ejm/4/1/0017DOI: 10.1127/ejm/4/1/0017
  2. 1993Armbruster, Thomas, Oberhänsli, Roland, Bermanec, Vladimir, Dixon, Roger D. (1993) Hennomartinite and kornite, two new Mn3+ rich silicates from the Wessels Mine, Kalahari, South Africa. Schweizerische Mineralogische und Petrographische Mitteilungen: 73: 349-355.
  3. 1994Jambor, J.L.; Puziewicz, J.; Roberts, A.C. (1994) New mineral names. American Mineralogist, 79 (7-8). p.763-767.
  4. 1996Libowitzky, Eugen, Armbruster, Thomas (1996) Lawsonite-type phase transitions in hennomartinite, SrMn2[Si2O7](OH)2·H2O. American Mineralogist, 81 (1) 9-18 doi:10.2138/am-1996-1-202 DOI: 10.2138/am-1996-1-202
  5. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
