Lawsonite

CaAl2(Si2O7)(OH)2 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lws

Where it forms, where it's found

Geological setting

Lawsonite forms at high pressures and low temperatures, especially in low-grade regionally metamorphosed glaucophane schists. It also forms from plagioclase during saussuritization of gabbros and diabases; rarely in eclogites.

Type locality
Reed Station
  1. Tiburon Peninsula
  2. Marin County
  3. California
  4. USA

37.9056°, -122.4927°

79recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
colorless · white · grayish blue · pale blue · pink
Streak
white
Cleavage
Perfect

[001] perfect [110] poor

Fracture
Irregular/Uneven
Density
3.1 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 84 – 85° · 2V calc = 76 – 86°
Refractive index
1.665 – 1.685
Surface relief
High
Principal indices
nα 1.665 · nβ 1.674 · nγ 1.685
Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#50
Cell parameters
a = 5.847 Å · b = 8.79 Å · c = 13.128 Å
Ratio a:b:c
1 : 1.503 : 2.245
Unit cell volume
674.72 ų
Z
4
Morphology

prismatic/tabular

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
50.92%
14SiSiliconSilicon228.08556.170
17.88%
13AlAluminiumAluminium226.98253.964
17.17%
20CaCalciumCalcium140.07840.078
12.75%
1HHydrogenHydrogen41.0084.032
1.28%
Total314.234100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
Lawsonite
German
Lawsonit
Spanish
lawsonita
Italian
lawsonite
Japanese
ローソン石
Chinese
硬柱石

Classification

Strunz
10th ed.

9.BE.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.05LawsoniteSpecies
Dana
8th ed.

56.02.03.01

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.03Lawsonite - Ilvaite groupGroup
  • 56.02.03.01LawsoniteSpecies
CIM

16.9.18

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.18LawsoniteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1895Ransome, Frederick Leslie (1895) On lawsonite, a new rock-forming mineral from the Tiburon Peninsula, Marin County. Bulletin of the Department of Geological Sciences, 1. 301-312
  2. 1896Ransome, F.L., Palache, C. (1896) Ueber Lawsonit en Neues gesteinbildendes Mineral aus Californien: Zeitschr. Kristallographie, Band 25: 531-537.
  3. 1904Schaller, W.T., Hillebrand, W.F. (1904) Crystallographical and chemical notes on lawsonite: American Journal of Science, 4th. Series: 17: 195-197.
  4. 1905Schaller, W.T., Hillebrand, W.F. (1905) Notes on lawsonite. United States Geological Survey Bulllletin: 262: 58-60.
  5. 1960Davis, G. A. (1960) Lawsonite and pumpellyite in glaucophane schist, North Berkeley Hills, California, with notes on the X-ray crystallography of lawsonite, by A. Pabst. American Journal of Science, 258 (10) 689-704 doi:10.2475/ajs.258.10.689DOI: 10.2475/ajs.258.10.689
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Lawsonite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/lawsonite-2353},
  note      = {Accessed 2026-05-11}
}
