Noelbensonite

BaMn3+2Si2O7(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Noe
Also known as
  • IMA1994-058
  • Noelbensoniet

Where it forms, where it's found

Geological setting

Rhodonite deposit.

Type locality
Woods Mine (Wood's Rhodonite Mine)
  1. Inglis Co.
  2. New South Wales
  3. Australia

-30.8017°, 151.0133°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy to brilliantly vitreous
Colour
Dark brown
Streak
Yellow-brown
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
3.87 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 46° · 2V calc = 46°
Refractive index
1.82 – 1.85
Surface relief
Very high
Principal indices
nα 1.82 · nβ 1.845 · nγ 1.85
Pleochroism
Visible

X = orange yellow; Y = orange; Z = brownish orange.

Dispersion
distinct to strong, r > v.
Extinction
Straight extinction to plane of flattening. X = c; Y = b; Z = a.
Notes

β calculated from 2V. Absorption Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 6.31303(2) Å · b = 9.0977(3) Å · c = 13.5820(4) Å
Ratio a:b:c
1 : 1.441 : 2.151
Morphology

Dominated by (100) and (011), with (011) ∧ (01_1) = 68°.

Twinning

None observed.

Type-locality form

Aggregates of blocky to lamellar crystals ranging from a few micrometres to (rarely) 100 µm in length. Tiny monomineralic veinlets 0.05-0.25 mm thick. Rare euhedral crystals.

Comment

Data for Sr-rich sample from Cametti et al. (2017); non-standard space-group setting P21cn. The type material was originally assumed to have space group Cmcm.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
34.23%
56BaBariumBarium1137.327137.327
29.38%
25MnManganeseManganese254.938109.876
23.51%
14SiSiliconSilicon228.08556.170
12.02%
1HHydrogenHydrogen41.0084.032
0.86%
Total467.395100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1994-058
  • Noelbensoniet

In other languages

German
IMA 1994-058 · Noelbensonit
Italian
Noelbensonite

Classification

Strunz
10th ed.

9.BE.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.05NoelbensoniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (6) 463-466
  2. 1996Kawachi, Y., Coombs, D. S., Miura, H. (1996) Noélbensonite, a new BaMn silicate of the lawsonite structure type, from Woods mine, New South Wales, Australia. Mineralogical Magazine, 60 (399) 369-374 doi:10.1180/minmag.1996.060.399.11 DOI: 10.1180/minmag.1996.060.399.11
  3. 2004Coombs, Douglas S., Kawachi, Yosuke, Miura, Hiroyuki, Chappell, Debra (2004) Cerchiaraite and Ca-bearing noelbensonite from Woods mine, New South Wales, Australia. European Journal of Mineralogy, 16 (1) 185-189 doi:10.1127/0935-1221/2004/0016-0185DOI: 10.1127/0935-1221/2004/0016-0185
  4. 2006Burke, A., Ferraris, G. (2006) New minerals approved in 2005 - Nomenclature modifications approved in 2005 by the Commission on New Minerals and Mineral Names - International Mineralogical Association. The Canadian Mineralogist, 44, 547-552.
  5. 2017Cametti, G., Armbruster, T., Hermann, J., Churakov, S. (2017) Crystal structure and phase transition in noelbensonite: a multi-methodological study. Physics and Chemistry of Minerals, 44 (7) 485-496 doi:10.1007/s00269-017-0876-3DOI: 10.1007/s00269-017-0876-3
