Itoigawaite

SrAl2Si2O7(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Ito
Discovered
1996
Also known as
  • IMA1998-034
  • Itoigawaiet

Where it forms, where it's found

Type locality
Oyashirazu Beach
  1. Ōmi
  2. Itoigawa City
  3. Niigata Prefecture
  4. Japan

37.0044°, 137.7319°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Blue
Streak
White
Cleavage
Distinct/Good

Good in one direction

Density
3.37 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60° · 2V calc = 81°
Refractive index
1.664 – 1.688
Surface relief
High
Principal indices
nα 1.664 · nβ 1.674 · nγ 1.688
Dispersion
observed moderate (also reported as "strong"); r > v
Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmcm
Cell parameters
a = 6.031(2) Å · b = 8.945(2) Å · c = 13.219(4) Å
Ratio a:b:c
1 : 1.483 : 2.192
Z
4
Type-locality form

Bluish mineral forming <0.8 mm veinlets in a lavender-coloured jadeite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
44.22%
38SrStrontiumStrontium187.62087.620
24.22%
14SiSiliconSilicon228.08556.170
15.53%
13AlAluminiumAluminium226.98253.964
14.92%
1HHydrogenHydrogen41.0084.032
1.11%
Total361.776100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-034
  • Itoigawaiet

In other languages

German
IMA 1998-034 · Itoigawait
Italian
Itoigawaite
Japanese
糸魚川石

Classification

Strunz
10th ed.

9.BE.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.05ItoigawaiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1999Miyajima, H., Matsubara, S., Miyawaki, R., Ito, K. (1999) Itoigawaite, a new mineral, the Sr analogue of lawsonite, in jadeitite from the Itoigawa-Ohmi district, central Japan. Mineralogical Magazine, 63 (6) 909-916 doi:10.1180/002646199548899 DOI: 10.1180/002646199548899
  2. 2000Jambor, J.L., Kovalenker, V.A., Roberts, A.C. (2000) New mineral names. American Mineralogist: 85: 873-877.
  3. 2003Shimobayashi, N., Yamada, S. (2003) Coexistence of itoigawaite and pumpellyite in jadeitite from Wakasa district, Tottori Prefecture, Japan. In Abstracts for Annual Meeting of the Mineralogical Society of Japan Abstracts for the Meeting (2003) of the Mineralogical Society of Japan, 133-133.
  4. 2004Shimobayashi, N. (2004) Sr-bearing silicate minerals-itoigawaite and niigataite-in jadeitites and the related rocks from Wakasa district, Tottori Prefecture, Japan. In Abstracts for Annual Meeting of the Mineralogical Society of Japan Abstracts for the Meeting (2004) of the Mineralogical Society of Japan, 106-106.
  5. 2021(2021) Itoigawaite. Handbook of Mineralogy. Mineralogical Society of America
