Hexahydrite

Mg(SO4) · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hhy
Discovered
1911
Also known as
  • Hexahydriet
  • Hexahydrita

Where it forms, where it's found

Type locality
Hexahydrite Type Locality
  1. Maggie claim group
  2. Kamloops Mining Division
  3. British Columbia
  4. Canada

50.9167°, -121.4000°

253recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Pearly · vitreous
Transparency
Transparent · Translucent
Colour
Colourless · white · pale greenish white · colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (100), perfect.

Fracture
Conchoidal
Density
1.757 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 38° · 2V calc = 36°
Refractive index
1.426 – 1.456
Surface relief
Low
Principal indices
nα 1.426 · nβ 1.453 · nγ 1.456
Dispersion
none
Extinction
Y = b; X ∧ c = 25°.
UV response
Fluoresces and phosphoresces dull cream white (Sterling Mine, Ogdensburg, NJ, USA).
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#13
Cell parameters
a = 24.44 Å · b = 7.21 Å · c = 10.11 Å
Cell angles
β = 98.28 °
Ratio a:b:c
1 : 0.295 : 0.414
Morphology

Good crystals rare; sometimes thick tabular (001). Also coarse columnar to delicately fibrous to acicular.

Twinning

1. On (001); 2. on (110).

Type-locality form

Seams (to about 1 cm thick) and scattered patches in altered rock. A somewhat coarse columnar structure or sometimes delictae fibrous. No distinct crystals observed.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
70.03%
16SSulfurSulfur132.06032.060
14.03%
12MgMagnesiumMagnesium124.30524.305
10.64%
1HHydrogenHydrogen121.00812.096
5.30%
Total228.451100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hexahydriet
  • Hexahydrita

In other languages

French
Hexahydrite
German
Hexahydrit
Italian
esaidrite · hexahydrite
Russian
гексагидрит

Classification

Strunz
10th ed.

7.CB.25

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CBWith only medium-sized cationsGroup
  • 7.CB.25HexahydriteSpecies
Dana
8th ed.

29.06.08.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.06AXO4·xH2OType
  • 29.06.08Hexahydrite Group (Space Group: C2/c)Group
  • 29.06.08.01HexahydriteSpecies
CIM

25.3.5

  • 25SulphatesClass
  • 25.3Sulphates of MgGroup
  • 25.3.5HexahydriteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
7 minerals

Literature, links & citation

Citations
  1. 1911Johnston, R.A.A. (1911) Hexahydrite, a new mineral. Summary Report of the Geological Survey Branch of the Department of Mines For the Calendar Year 1910: 26: 256-257.
  2. 1913Spencer, L. J. (1913) A (sixth) list of new mineral names. Mineralogical Magazine and Journal of the Mineralogical Society, 16 (77) 352-378 doi:10.1180/minmag.1913.016.77.09 DOI: 10.1180/minmag.1913.016.77.09
  3. 1927Walker and Parsons (1927) University of Toronto Stud., Geology Service: 24: 21.
  4. 1927Robson, Homer Louis (1927) The system MgSO4·H2O from 68 to 240°. Journal Of The American Chemical Society, 49 (11). 2772-2783 doi:10.1021/ja01410a016DOI: 10.1021/ja01410a016
  5. 1929Dolivo-Dobrovolsky (1929) Mineralogicheskoe Obshchestvo, Leningrad, Zapiski: [2]: 58: 3.
