Jervisite

NaSc3+Si2O6
IMA status
  • Approved
IMA symbol
Je
Discovered
1982

Where it forms, where it's found

Geological setting

Granite

Type locality
Giacomini Quarry (Diverio Quarry
  1. Bottigetto Quarry)
  2. Agrano
  3. Omegna
  4. Verbano-Cusio-Ossola Province
  5. Piedmont
  6. Italy

45.8689°, 8.4443°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Light green
Streak
white
Cleavage
Perfect

Optical

Optical type
Biaxial (+) · 2V calc = 69.2°
Refractive index
1.684 – 1.733
Surface relief
High
Principal indices
nα 1.684 · nβ 1.704 · nγ 1.733
Dispersion
None
Notes

X is parallel to the c axis, Y is parallel to the b axis, and Z is parallel to the a axis. Optical data from Vignola et al. 2019.

Michel-Lévy diagramhighlighted lineδ = 0.0490
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]490 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation490 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 9.8478(2) Å · b = 9.0575(1) Å · c = 5.3409(3) Å
Cell angles
β = 106.82(7) °
Ratio a:b:c
1 : 0.920 : 0.542
Unit cell volume
455.89 ų
Z
4
Morphology

Dominant forms (100) and (010); less-developed are (141), (221), and (001).

Type-locality form

Tufts of platelets to about 0.20 x 0.08 x 0.02 mm in size.

Comment

Vignola et al. 2019

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
43.61%
14SiSiliconSilicon228.08556.170
25.52%
21ScScandiumScandium144.95644.956
20.42%
11NaSodiumSodium122.99022.990
10.45%
Total220.110100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Mn

In other languages

German
IMA 1980-012 · Jervisit
Italian
Jervisite

Classification

Strunz
10th ed.

9.DA.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.25JervisiteSpecies
Dana
8th ed.

65.01.3c.06

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.3c— unnamed intermediate level —Group
  • 65.01.3c.06JervisiteSpecies
CIM

14.8.12

  • 14Silicates not Containing AluminumClass
  • 14.8Silicates of Group III metals other than AlGroup
  • 14.8.12JervisiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1968Ito, Jun, Frondel, Clifford (1968) Syntheses of the scandium analogues of aegirine, spodumene, andradite and melanotekite. American Mineralogist, 53 (7-8) 1276-1280
  2. 1969Clark, J.R., Appleman, D.E., Papike, J.J. (1969) Crystal-chemical characterization of clinopyroxenes based on eight new structure refinements. MSA Special Paper: 2: 31-50.
  3. 1973Hawthorne, F. C., Grundy, H. D. (1973) Refinement of the crystal structure of NaScSi2O6. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 29 (11) 2615-2616 doi:10.1107/s0567740873007156DOI: 10.1107/s0567740873007156
  4. 1982Mellini, M., Merlino, S., Orlandi, P., Rinaldi, R. (1982): Cascandite and jervisite, two new scandium silicates from Baveno, Italy. American Mineralogist, 67: 599-603.
  5. 1988Morimoto, N. (1988) Nomenclature of Pyroxenes. Mineralogy and Petrology, 39 (1). 55-76 doi:10.1007/bf01226262 DOI: 10.1007/bf01226262
