Johannsenite

CaMnSi2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Jhn
Discovered
1932

Where it forms, where it's found

Type locality
Temperino Mine
  1. Campiglia Marittima
  2. Livorno Province
  3. Tuscany
  4. Italy

43.0742°, 10.6175°

94recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark brown · pale brownish · blue-green · pale greenish · grey-white · colourless

Depends on content of iron and other impurities.

Streak
white
Cleavage
Distinct/Good
Fracture
Irregular/Uneven · Step-Like
Density
3.56 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 68 – 70° · 2V calc = 64 – 82°
Refractive index
1.703 – 1.745
Surface relief
High
Principal indices
nα 1.703 – 1.716 · nβ 1.711 – 1.728 · nγ 1.732 – 1.745
Birefringence
0.029
Dispersion
r > v weak
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 9.87 Å · b = 9.04 Å · c = 5.27 Å
Cell angles
β = 105.54 °
Ratio a:b:c
1 : 0.916 : 0.534
Z
4
Comment

Freed R L , Peacor D R , American Mineralogist , 52 (1967) p.709-720, Refinement of the crystal structure of johannsenite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
38.84%
14SiSiliconSilicon228.08556.170
22.72%
25MnManganeseManganese154.93854.938
22.23%
20CaCalciumCalcium140.07840.078
16.21%
Total247.180100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mg
  • Na
  • K
  • C
  • P
  • H2O

In other languages

French
Johannsénite
German
Johannsenit
Spanish
Johannsenita
Italian
Johannsenite
Japanese
ヨハンセナイト · ヨハンセン輝石
Chinese
钙锰辉石
Russian
Йохансенит

Classification

Strunz
10th ed.

9.DA.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.15JohannseniteSpecies
Dana
8th ed.

65.01.3a.04

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.3a— unnamed intermediate level —Group
  • 65.01.3a.04JohannseniteSpecies
CIM

14.18.18

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.18JohannseniteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1938Schaller, Waldemar T. (1938) Johannsenite, a new manganese pyroxene. American Mineralogist, 23 (9) 575-582
  2. 1953Allen, Victor T.; Fahey, Joseph J. (1953) Rhodonite, johannsenite, and ferroan johannsenite at Vanadium, New Mexico. American Mineralogist, 38 (11-12). 883-890
  3. 1956Hutton, C. Osborne (1956) Manganpyrosmalite, bustamite, and ferroan johannsenite from Broken Hill, New South Wales, Australia. American Mineralogist, 41 (7-8) 581-591
  4. 1963Simons, Frank S., Munson, Elaine (1963) Johannsenite from the Aravaipa mining district, Arizona. American Mineralogist, 48 (9-10). 1154-1158
  5. 1965Frondel, Clifford (1965) Johannsenite and manganoan hortonolite from Franklin, N. J. American Mineralogist, 50 (5-6). 780-782
