Kanoite

MnMgSi2O6
IMA status
  • Approved
IMA symbol
Knt
Discovered
1977

Where it forms, where it's found

Geological setting

Seam cutting a pyroxmangite-cummingtonite metamorphic rock.

Type locality
Tatehira mine
  1. Kumaishi
  2. Yakumo
  3. Futami District
  4. Oshima Subprefecture
  5. Hokkaidō Prefecture
  6. Japan
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pinkish brown
Streak
Pale brown to white
Cleavage
Perfect

(110)

Density
3.66 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40 – 42°
Refractive index
1.715 – 1.728
Surface relief
High
Principal indices
nα 1.715 · nβ 1.715 · nγ 1.728
Dispersion
r > v
Extinction
Y = b; Z ∧ c = 42°.
Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 9.73 Å · b = 8.93 Å · c = 5.26 Å
Cell angles
β = 108.56 °
Ratio a:b:c
1 : 0.918 : 0.541
Z
4
Morphology

Grains to 0.1 mm.

Twinning

Polysynthetic twinning on (100) is common.

Type-locality form

Grains to 0.1 X 0.1 mm in maximum.

Comment

Space group probable

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
41.48%
14SiSiliconSilicon228.08556.170
24.28%
25MnManganeseManganese154.93854.938
23.74%
12MgMagnesiumMagnesium124.30524.305
10.50%
Total231.407100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Ca
  • Na
  • K

In other languages

German
IMA 1977-020 · Kanoit
Spanish
Kanoíta
Italian
Kanoite
Japanese
加納輝石

Classification

Strunz
10th ed.

9.DA.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.10KanoiteSpecies
Dana
8th ed.

65.01.01.03

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.01P2/c clinopyroxenesGroup
  • 65.01.01.03KanoiteSpecies
CIM

14.18.8

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.8KanoiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1969Clark, J.R., Appleman, D.E., Papike, J.J. (1969) Crystal-chemical characterization of clinopyroxenes based on eight new structure refinements. MSA Special Paper: 2: 31-50.
  2. 1977Kobayashi, H. (1977): Kanoite, (Mn2+,Mg)2[Si2O6], a new clinopyroxene in the metamorphic rock from Tatehira, Oshima Peninsula, Hokkaido, Japan. Chishitsugaku Zasshi 83, 537-542.
  3. 1978Fleischer, Michael, Cabri, Louis J. (1978) New mineral names. American Mineralogist, 63 (5-6) 598-600
  4. 1989Morimoto, N. (1989) Nomenclature of pyroxenes. The Canadian Mineralogist: 27: 143-156.
  5. 1996Gnos, Edwin, Armbruster, Thomas, Nyfeler, Daniel (1996) Kanoite, donpeacorite and tirodite: Mn-Mg-silicates from a manganiferous quartzite in the United Arab Emirates. European Journal of Mineralogy, 8 (2) 251-262 doi:10.1127/ejm/8/2/0251DOI: 10.1127/ejm/8/2/0251
