Kosmochlor

NaCr3+Si2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Kos
Discovered
1897
Also known as
  • Chrome-Acmite
  • Cloromelanitite
  • Cosmochlore
  • +2 more

Where it forms, where it's found

Geological setting

e jadeitites

Type locality
Toluca meteorite
  1. Jiquipilco (Xiquipilco)
  2. Mexico
  3. Mexico

19.5667°, -99.5667°

22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Emerald-green · dark green
Streak
pale green
Cleavage
Distinct/Good

Good on (110)

Density
3.51 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 6 – 70°
Refractive index
1.74 – 1.781
Surface relief
High
Principal indices
nα 1.740 – 1.766 · nβ 1.756 – 1.778 · nγ 1.745 – 1.781
Pleochroism
Strong

X = yellowish green; Y = blue-green, grass-green; Z = emerald-green.

Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 9.550 Å · b = 8.712 Å · c = 5.273 Å
Cell angles
β = 107.44 °
Ratio a:b:c
1 : 0.912 : 0.552
Z
4
Twinning

Simple, lamellar on (100), (001).

Parting
parting on (001)
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
42.26%
14SiSiliconSilicon228.08556.170
24.73%
24CrChromiumChromium151.99651.996
22.89%
11NaSodiumSodium122.99022.990
10.12%
Total227.150100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mn
  • Mg
  • Ca
  • K
  • P

Synonyms

  • Chrome-Acmite
  • Cloromelanitite
  • Cosmochlore
  • IMA1965-007
  • Ureyite

In other languages

French
Chrome-acmite · Cloromelanitite · Cosmochlore · Kosmochlor · Ureyite
German
IMA 1965-007 · Kosmochlor
Italian
Cosmocloro · Kosmochlor
Portuguese
IMA1965-007
Japanese
コスモクロア輝石
Russian
Космохлор

Classification

Strunz
10th ed.

9.DA.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.25KosmochlorSpecies
Dana
8th ed.

65.01.3c.04

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.3c— unnamed intermediate level —Group
  • 65.01.3c.04KosmochlorSpecies
CIM

14.15.1

  • 14Silicates not Containing AluminumClass
  • 14.15Silicates of CrGroup
  • 14.15.1KosmochlorSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1897Laspeyres, H. (1897) Die steinigen Gemengtheile im Meteoreisen von Toluca in Mexico. Zeitschrift für Krystallographie und Mineralogie: 27: 586–600.
  2. 1965Fleischer, Michael (1965) New Mineral Names. American Mineralogist, 50 (11-12) 2096-2111
  3. 1965Gübelin, E. (1965): Maw-sit-sit proves to be jade-albite. J. Gemmology 9 (11), 372-379. [as "chrome-jadeite"]
  4. 1965Frondel, C., Klein, C. (1965) Ureyite, NaCrSi2O6: A New Meteoritic Pyroxene. Science, 149 (3685). 742-744 doi:10.1126/science.149.3685.742DOI: 10.1126/science.149.3685.742
  5. 1967Neuhaus, A. (1967) Über Kosmochlor (Ureyit). Die Naturwissenschaften, 54 (15). 440-441 doi:10.1007/bf00603143DOI: 10.1007/bf00603143
