Lavendulan

NaCaCu5(AsO4)4Cl · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lvd
Discovered
1837
Also known as
  • Freirinite
  • Lavendulaan
  • Lavendulane
  • +6 more

Where it forms, where it's found

Geological setting

Secondary mineral in the oxidized zone of some copper deposits.

Type locality
Jáchymov
  1. Karlovy Vary District
  2. Karlovy Vary Region
  3. Czech Republic

50.3661°, 12.9233°

168recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Turquoise-blue · greenish blue · pale blue
Cleavage
Distinct/Good

Good on (010) Distinct on (100) (001)

Density
3.54 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 33° · 2V calc = 58°
Refractive index
1.66 – 1.734
Surface relief
High
Principal indices
nα 1.66 · nβ 1.715 · nγ 1.734
Pleochroism
Visible

O= pale blue to pale greenish blue E= blue to greenish blue

Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0740
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]740 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation740 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 10.011 Å · b = 19.478 Å · c = 10.056 Å
Cell angles
β = 90.37 °
Ratio a:b:c
1 : 1.946 : 1.004
Unit cell volume
1960.8 ų
Z
4
Morphology

Thin rectangular, pseudo-orthorhombic plates.

Twinning

Commmon.

Comment

Space group P21/n. Pseudo-orthorhombic metrics.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
31.64%
29CuCopperCopper563.546317.730
29.92%
33AsArsenicArsenic474.922299.688
28.22%
20CaCalciumCalcium140.07840.078
3.77%
17ClChlorineChlorine135.45035.450
3.34%
11NaSodiumSodium122.99022.990
2.16%
1HHydrogenHydrogen101.00810.080
0.95%
Total1061.995100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Freirinite
  • Lavendulaan
  • Lavendulane
  • Lavendulanit
  • Lavendulanita
  • Lavendulanite
  • Lavendulit
  • Lavendulita
  • Lavendulite

In other languages

French
Lavendulan
German
Lavendulan
Spanish
Lavendulana
Italian
Lavendulano
Russian
Лавендулан

Classification

Strunz
10th ed.

8.DG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DGWith large and medium-sized cations, (OH, etc.):RO4< 0.5:1Group
  • 8.DG.05LavendulanSpecies
Dana
8th ed.

42.09.04.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.09(AB)7(XO4)4Zq·xH2OType
  • 42.09.04— unnamed intermediate level —Group
  • 42.09.04.02LavendulanSpecies
CIM

22.2.2

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.2Phosphates, arsenates or vanadates with chlorideGroup
  • 22.2.2LavendulanSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1837Breithaupt, A. (1837) Bestimmung neuer Mineralien. 3. Lavendulan. Journal für praktische Chemie: 10: 505-506.
  2. 1877Goldsmith, E. (1877) On lavendulite from Chile, S.A. Proceedings of the Academy of Sciences Philadelphia: 192-193.
  3. 1924Foshag, William F. (1924) Note on lavendulan from Joachimstal, Bohemia. American Mineralogist, 9 (2) 29
  4. 1924Foshag, W.F. (1924) Freirinite: A new mineral species. American Mineralogist: 9: 30-31. (as freirinite).
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
