Leucophanite

NaCaBeSi2O6F
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lph
Discovered
1824
Also known as
  • Leucophane
  • Leucophaniet
  • Leucophanit
  • +2 more

Where it forms, where it's found

Geological setting

Nepheline syenite pegmatite.

Type locality
Låven
  1. Larvik Commune
  2. Vestfold
  3. Norway

58.9956°, 9.8175°

48recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale yellow · greenish white · yellowish green · colourless
Streak
White
Tenacity
very brittle
Cleavage
Perfect

On (001), distinct on (100),(010) and [201}.

Fracture
Irregular/Uneven · Conchoidal
Density
2.96 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 36 – 50° · 2V calc = 38°
Refractive index
1.571 – 1.598
Surface relief
Moderate
Principal indices
nα 1.571 · nβ 1.595 · nγ 1.598
Dispersion
r > v
Extinction
X = c; Y = a; Z = b.
UV response
Triboluminescent with orange red light (http://www.mindat.org/mesg-6-204391.html). Pink, rarely blue in SW and LW UV light. strongly phosphorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 7.401(2) Å · b = 7.412 Å · c = 9.990(2) Å
Ratio a:b:c
1 : 1.001 : 1.350
Z
2
Morphology

Pinacoids (100), (010) and (001), prisms (110), (201), sphenoids (111) and(111). Other forms include (101), (102), (113).

Twinning

Penetration fourlings; polysynthetic parallel to (110).

Type-locality form

Masses.

Comment

Pseudotetragonal. Space Group: P 1: a = 7.417(4) b = 7.398(4) c = 9.986(4) ® = 90:00(2) ± ¯ = 90:00(2) ± ° = 90:00(2) ± Z = 2

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
39.46%
14SiSiliconSilicon228.08556.170
23.09%
20CaCalciumCalcium140.07840.078
16.48%
11NaSodiumSodium122.99022.990
9.45%
9FFluorineFluorine118.99818.998
7.81%
4BeBerylliumBeryllium19.0129.012
3.71%
Total243.242100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • K
  • H2O

Synonyms

  • Leucophane
  • Leucophaniet
  • Leucophanit
  • Leucophanita
  • Leukophanit

In other languages

French
Leucophanite
German
Leukophan
Spanish
Leucofanita
Italian
Leucofanite · Leucophanite
Japanese
リューコフェン石
Chinese
白鈹石

Classification

Strunz
10th ed.

9.DH.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DHInosilicates with 4-periodic single chains, Si4O12Group
  • 9.DH.05LeucophaniteSpecies
Dana
8th ed.

55.04.02.04

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.04Si2O7 Groups, Generally with No Additional Anions with cations in [8] and lower coordinationType
  • 55.04.02Fresnoite groupGroup
  • 55.04.02.04LeucophaniteSpecies
CIM

17.1.8

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.8LeucophaniteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1839Tamnau, (1839) Ueber den Leukophan. Annalen der Physik und Chemie, 124. 504 doi:10.1002/andp.18391241111DOI: 10.1002/andp.18391241111
  2. 1840Erdmann, Axel (1840) Undersökning af leucophan, ett nytt mineral frän trakten af Brewig i Norrige [Investigation of leucophan, a new mineral from the area of Brewig in Noway]. Kungliga Svenska vetenskapsakademiens handlingar, S. 3 Vol. 28. 191-200
  3. 1856Rammelsberg, C. (1856) Ueber die Identität des Leucophans und Melinophans. Annalen der Physik und Chemie, 174. 257-261 doi:10.1002/andp.18561740608DOI: 10.1002/andp.18561740608
  4. 1873Bertrand, Émile (1873) Note sûr la forme crystalline du leucophane [Note on the crystalline form of leucophane]. Annales des Mines, S. 7 Vol. 3. 24-25
  5. 1877Bertrand, E. (1877) Note on the law of twinning an hemihedrism of leucophane. In Proceedings of the Crystallological society. Part I. Taylor & Francis, Red Lion Court, Fleet Street. p.35-37.
