Astrophyllite

K2NaFe2+7Ti2(Si4O12)2O2(OH)4F
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ast
Discovered
1844
Also known as
  • Aastrophyllit
  • Aastrophyllita
  • Aastrophyllite
  • +6 more

Where it forms, where it's found

Geological setting

Nepheline-syenite pegmatite.

Nepheline syenites and alkali granites.

Type locality
Låven
  1. Larvik Commune
  2. Vestfold
  3. Norway

58.9956°, 9.8175°

169recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sub-metallic · pearly
Transparency
Translucent · Opaque
Colour
Bronze-yellow · golden yellow · brown to reddish brown
Streak
Golden
Tenacity
brittle
Cleavage
Perfect

Perfect on (001) Poor on (100)

Fracture
Irregular/Uneven
Density
3.2 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 70 – 90° · 2V calc = 80°
Refractive index
1.68 – 1.73
Surface relief
High
Principal indices
nα 1.68 · nβ 1.7 · nγ 1.73
Pleochroism
Strong

X= deep red-orange Y= orange-yellow Z= lemon-yellow

Dispersion
none
Extinction
X ≃ c; Y ≃ b; Z ≃ a.
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.3866 Å · b = 11.8821 Å · c = 11.6794 Å
Cell angles
α = 113.019 ° · β = 94.578 ° · γ = 103.120 °
Ratio a:b:c
1 : 2.206 : 2.168
Morphology

Tabular, bladed, acicular.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
36.48%
26FeIronIron755.845390.915
29.72%
14SiSiliconSilicon828.085224.680
17.08%
22TiTitaniumTitanium247.86795.734
7.28%
19KPotassiumPotassium239.09878.196
5.94%
11NaSodiumSodium122.99022.990
1.75%
9FFluorineFluorine118.99818.998
1.44%
1HHydrogenHydrogen41.0084.032
0.31%
Total1315.515100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Nb
  • Ta
  • Zr
  • Al
  • Mg
  • Ca

Synonyms

  • Aastrophyllit
  • Aastrophyllita
  • Aastrophyllite
  • Asterophyllit
  • Asterophyllita
  • Asterophyllite
  • Astrophengit
  • Astrophylliet
  • Astrophyllita

In other languages

French
astrophyllite
German
Astrophyllit
Spanish
Astrofillita
Italian
Astrofillite
Japanese
星葉石
Chinese
星葉石
Russian
астрофиллит
Arabic
أستروفيليت

Classification

Strunz
10th ed.

9.DC.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DCInosilicates with branched 2-periodic single chains; Si2O6 + 2SiO3 Si4O12Group
  • 9.DC.05AstrophylliteSpecies
Dana
8th ed.

69.01.01.01

  • 69Inosilicates Chains with Side Branches or LoopsClass
  • 69.01Chains with Side Branches or Loops with (P=2, and N=4, 2 branches)Type
  • 69.01.01Astrophyllite groupGroup
  • 69.01.01.01AstrophylliteSpecies
CIM

14.9.29

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.29AstrophylliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1848Weibye, Paul Christian (1848) Beiträge zur topograpischen Mineralogie Norwegens. Archiv für Mineralogie, Geognosie, Bergbau und Hüttenkunde, 22. 465-544
  2. 1854Scheerer, Th. (1854) Verhandlungen des bergmännischen Vereins zu Freiberg [Negotiations of the Miners' Association of Freiberg]. Berg - und hüttenmännische Zeitung. Mit besonderer Brücksichtigung der Mineralogie und Geologie, 8 (13). 239-240
  3. 1864Scheerer, Th. (1864) Ueber den Astrophyllit und sein Verhältniss zu Augit und Glimmer im Zirkonsyenit, nebst Bemerkungen über die plutonische Entstehung solcher Gebilde. Annalen der Physik und Chemie, 198. 107-138 doi:10.1002/andp.18641980507DOI: 10.1002/andp.18641980507
  4. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  5. 1967Woodrow, P. J. (1967) The crystal structure of astrophyllite. Acta Crystallographica, 22 (5) 673-678 doi:10.1107/s0365110x67001331DOI: 10.1107/s0365110x67001331
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Astrophyllite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/astrophyllite-405},
  note      = {Accessed 2026-05-11}
}
