Lindgrenite

Cu3(Mo6+O4)2(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lgr
Discovered
1935
Also known as
  • Lindgreniet

Where it forms, where it's found

Geological setting

Oxidized zone of a copper deposit.

Type locality
Chuquicamata Mine
  1. Chuquicamata District
  2. Calama
  3. El Loa Province
  4. Antofagasta
  5. Chile

-22.2894°, -68.9011°

20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Green · yellowish green · pale green to yellow-green in transmitted light
Streak
Pale green
Tenacity
brittle
Cleavage
Perfect

On (010), perfect; on (101) and (100), very poor.

Fracture
Micaceous
Density
4.2 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 71° · 2V calc = 50°
Refractive index
1.93 – 2.02
Surface relief
Very high
Principal indices
nα 1.930 · nβ 2.002 · nγ 2.020
Birefringence
0.090
Dispersion
r > v strong
Extinction
Z ∧ c = 9°.
Michel-Lévy diagramhighlighted lineδ = 0.0900
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]900 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation900 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 5.394 Å · b = 14.023 Å · c = 5.608 Å
Cell angles
β = 98.5 °
Ratio a:b:c
1 : 2.600 : 1.040
Z
2
Morphology

Crystals tabular or platy (010), exhibiting (010), which may be striated parallel [001]. Also may exhibit forms (100), (021), and several others. Rarely acicular along [101] with a square outline; crusts; massive. Forms include (001), (010), (100), (120), (110), (210), (012), (101), (111), (113), (111), (121). (121), (131).

Type-locality form

Thin green plates, with brilliant facets on their edges to a maximum diameter of about 4 mm.

Comment

Space group = P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
42MoMolybdenumMolybdenum295.950191.900
35.24%
29CuCopperCopper363.546190.638
35.01%
8OOxygenOxygen1015.999159.990
29.38%
1HHydrogenHydrogen21.0082.016
0.37%
Total544.544100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Lindgreniet

In other languages

French
Lindgrenite
German
Lindgrenit
Spanish
Lindgrenita
Italian
Lindgrenite
Japanese
リンドグレン石

Classification

Strunz
10th ed.

7.GB.05

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.05LindgreniteSpecies
Dana
8th ed.

48.03.01.01

  • 48Anhydrous Molybdates and TungstatesClass
  • 48.03Basic Anhydrous Molybdates and TungstatesType
  • 48.03.01— unnamed intermediate level —Group
  • 48.03.01.01LindgreniteSpecies
CIM

27.3.1

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.3MolybdatesGroup
  • 27.3.1LindgreniteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1935Palache, Charles (1935) Lindgrenite, a new mineral. American Mineralogist, 20 (7) 484-491
  2. 1938Bandy, Mark C. (1938) Mineralogy of three sulphate deposits of northern Chile. American Mineralogist, 23 (11) 669-760
  3. 1949Barnes, William H. (1949) The unit cell and space group of lindgrenite. American Mineralogist, 34 (3-4) 163-172
  4. 1949Barnes, William H. (1949) Corrections to recent papers on probertite and lindgrenite. American Mineralogist, 34 (7-8) 611-613
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
