Powellite

Ca(MoO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pwl
Discovered
1891

Where it forms, where it's found

Geological setting

Chimneys of ore along a contact between limestone and granite.

Oxidation zone of hydrothermal deposits

Type locality
Peacock Mine
  1. Cuprum
  2. Seven Devils Mining District
  3. Adams County
  4. Idaho
  5. USA

45.1691°, -116.6511°

518recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine or greasy
Transparency
Transparent · Translucent
Colour
Yellow · straw-yellow · yellow-brown · brown · greenish yellow · grey · blue or black · colourless · black material is deep blue in transmitted light.

May exhibit zoned colouration.

Streak
white
Cleavage
Poor/Indistinct

Indistinct on (112) (011) and (001).

Fracture
Irregular/Uneven
Density
4.26 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.974 – 1.984
Surface relief
Very high
Principal indices
nω 1.974 · nε 1.984
Pleochroism
Visible

In deeply colored specimens (Houghton County, Michigan, USA): O = Blue E = Green

UV response
Creamy white or yellow to golden yellow (SW UV).
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#136
Cell parameters
a = 5.222(1) Å · c = 11.425(3) Å
Unit cell volume
312.92 ų
Z
4
Morphology

Crystals dipyramidal (111), with (011) and (112); less commonly flat tabular to paper-thin on (001), exhibiting many minor forms. Form e sometimes striated parallel to the intersection with vertical plane (110); diagonal striations parallel to (131) observed on e and W. Tetragonal-dipyramidal symmetry evident only in the zones of [_1_11]. Forms crusts; powdery; ocherous; massive.

Type-locality form

Well formed pyramidal crystals up to 2.5 mm in length, very similar in appearance to scheelite.

Comment

On synthetic material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
42MoMolybdenumMolybdenum195.95095.950
47.97%
8OOxygenOxygen415.99963.996
31.99%
20CaCalciumCalcium140.07840.078
20.04%
Total200.024100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • W

In other languages

French
Powellite
German
Powellit
Spanish
Powellita
Italian
powellite
Japanese
パウエル石
Chinese
鉬鈣礦
Arabic
باوليت

Classification

Strunz
10th ed.

7.GA.05

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GAWithout additional anions or H2OGroup
  • 7.GA.05PowelliteSpecies
Dana
8th ed.

48.01.02.02

  • 48Anhydrous Molybdates and TungstatesClass
  • 48.01AXO4Type
  • 48.01.02Scheelite SeriesGroup
  • 48.01.02.02PowelliteSpecies
CIM

27.3.2

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.3MolybdatesGroup
  • 27.3.2PowelliteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1889Hintze, Carl (1889) Handbuch der Mineralogie. Berlin and Leipzig. 6 volumes: 1 [3B]: 4036.
  2. 1891Melville, W.H. (1891) Powellite - calcium molybdate: A new mineral species. American Journal of Science: 141: 138-141.
  3. 1893Koenig, G.A., Hubbard, L.L. (1893) On powellite from a new locality [Houghton County, Michigan]. American Journal of Science: 46: 356-358.
  4. 1894Michel, L. (1894) Production artificielle de la Powellite. Bulletin de la Société française de Minéralogie: 17: 612-614.
  5. 1899Palache, C. (1899) Powellite crystals from Michigan. American Journal of Science: 7: 367-369.
