Nickeltsumcorite

Pb(Ni,Fe3+)2(AsO4)2(H2O,OH)2
IMA status
  • Approved
IMA symbol
Ntsm
IMA approved
2013
Also known as
  • IMA2013-117
  • Nickeltsumcoriet
  • Unnamed (Ni-analogue of Cobalttsumcorite)

Where it forms, where it's found

Geological setting

oxidation zone of a hydrothermal orebody

Type locality
Km 3 open pit
  1. Km 3 mines
  2. Km 3
  3. Lavreotiki
  4. East Attica
  5. Attica
  6. Greece

37.7201°, 24.0345°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Yellow · brownish-yellow · light brown or brown
Streak
Yellow
Tenacity
brittle
Cleavage
Distinct/Good

one direction

Density
5.02 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.82 – 1.9
Surface relief
Very high
Principal indices
nα 1.82 · nβ 1.87 · nγ 1.90
Notes

2V(obs.) is large

Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.124(8) Å · b = 6.339(3) Å · c = 7.567(7) Å
Cell angles
β = 115.19(6) °
Ratio a:b:c
1 : 0.695 : 0.829
Unit cell volume
396 ų
Z
2
Type-locality form

(1) coarse radial spherulites or dense concentric nodules, up to 0.15 mm in diameter, forming open-work aggregates and interrupted crusts, up to 3 × 5 mm (and up to 0.2 mm thick); (2) bunches or hemispherical clusters of crude individuals and separate, im

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
26.42%
8OOxygenOxygen1215.999191.988
24.49%
33AsArsenicArsenic274.922149.844
19.11%
28NiNickelNickel258.693117.386
14.97%
26FeIronIron255.845111.690
14.24%
1HHydrogenHydrogen61.0086.048
0.77%
Total784.156100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe(III)
  • Ca

Synonyms

  • IMA2013-117
  • Nickeltsumcoriet
  • Unnamed (Ni-analogue of Cobalttsumcorite)

In other languages

German
IMA 2013-117 · Nickeltsumcorit
Italian
nickeltsumcorite

Classification

Strunz
10th ed.

8.CG.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.15NickeltsumcoriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. U. Kolitsch et al. (unpublished data)
  2. 2004Kolitsch, Uwe; Blaß, Günter; Graf, Hans-Werner; Gröbner, Joachim (2004) Neufunde aus der Grube Clara im mittleren Schwarzwald [New finds from the Clara mine in the central Black Forest]. Lapis, 29 (2). 18-23; 50
  3. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) New minerals and nomenclature modifications approved in 2014, CNMNC Newsletter No 19. Mineralogical Magazine, 78 (1) 165-170 doi:10.1180/minmag.2014.078.1.12DOI: 10.1180/minmag.2014.078.1.12
  4. 2016Pekov, Igor V., Chukanov, Nikita V., Varlamov, Dmitry A., Belakovskiy, Dmitry I., Turchkova, Anna G., Voudouris, Panagiotis, Katerinopoulos, Athanassios, Magganas, Andreas (2016) Nickeltsumcorite, Pb(Ni,Fe3+)2(AsO4)2(H2O,OH)2, a new tsumcorite-group mineral from Lavrion, Greece. Mineralogical Magazine, 80 (2). 337-346 doi:10.1180/minmag.2016.080.003DOI: 10.1180/minmag.2016.080.003
  5. 2017(2017) Nickeltsumcorite. Handbook of Mineralogy. Mineralogical Society of America
