Ferrilotharmeyerite

CaZnFe3+(AsO4)2(OH) · H2O
IMA status
  • Approved
IMA symbol
Flmy
Discovered
1986
IMA approved
1986
Also known as
  • Ferrilotharmeyeriet
  • IMA1986-024

Where it forms, where it's found

Geological setting

Dolostone hosted hydrothermal polymetallic ore deposit

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

7recorded occurrences
Source · OpenStreetMap

Varieties

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine · Greasy
Transparency
Translucent
Colour
Brownish-yellow · yellow
Streak
Light yellow
Tenacity
brittle
Cleavage
Distinct/Good

Good on (001)

Fracture
Irregular/Uneven
Density
4.25 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40° · 2V calc = 44°
Refractive index
1.83 – 1.87
Surface relief
Very high
Principal indices
nα 1.83 · nβ 1.835 · nγ 1.87
Birefringence
0.040
Pleochroism
Strong

X= olive green or orange Y= pale green or yellow Z= colorless

Dispersion
r > v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.010(3) Å · b = 6.246(2) Å · c = 7.391(2) Å
Cell angles
β = 115.52(3) °
Ratio a:b:c
1 : 0.693 : 0.820
Z
2
Morphology

Short wedge-shaped to tabular crystals

Type-locality form

multiple subhedral crystallites, averaging 0.2 mm in length, with crudely formed faces slightly elongate in the b direction

Comment

Also a 8.98, b 6.230, c 7.380, beta 115.57

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
33.74%
33AsArsenicArsenic274.922149.844
31.60%
30ZnZincZinc165.38065.380
13.79%
26FeIronIron155.84555.845
11.78%
20CaCalciumCalcium140.07840.078
8.45%
1HHydrogenHydrogen31.0083.024
0.64%
Total474.161100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu
  • Al
  • Pb

Synonyms

  • Ferrilotharmeyeriet
  • IMA1986-024

In other languages

German
Ferrilotharmeyerit · IMA 1986-024
Italian
Ferrilotharmeyerite

Classification

Strunz
10th ed.

8.CG.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.15FerrilotharmeyeriteSpecies
Dana
8th ed.

37.01.06.02

  • 37Anhydrous Acid Phosphates, Arsenates and VanadatesClass
  • 37.01MiscellaneousType
  • 37.01.06Lotharmeyerite SeriesGroup
  • 37.01.06.02FerrilotharmeyeriteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1992Ansell, Valerie E., Ansell, Gary H., Roberts, Andrew C., Dunn, Pete J., Birch, William D., Grice, Joel D. (1992) Ferrilotharmeyerite, a new Ca-Zn-Fe3+ hydroxyl arsenate from Tsumeb, Namibia. The Canadian Mineralogist, 30 (1) 225-227
  2. 1998Krause, Werner, Belendorff, Klaus, Bernhardt, Heinz-Jürgen, Mccammon, Catherine, Effenberger, Herta, Mikenda, Werner (1998) Crystal chemistry of the tsumcorite-group minerals. New data on ferrilotharmeyerite, tsumcorite, thometzekite, mounanaite, helmutwinklerite, and a redefinition of gartrellite. European Journal of Mineralogy, 10 (2). 179-206 doi:10.1127/ejm/10/2/0179DOI: 10.1127/ejm/10/2/0179
  3. 2005(2005) Ferrilotharmeyerite. Handbook of Mineralogy. Mineralogical Society of America
