Nimite

(Ni,Mg,Al)6(Si,Al)4O10(OH)8
IMA status
  • Approved
IMA symbol
Nim
Discovered
1968
Also known as
  • Schuchardite

Where it forms, where it's found

Type locality
Bon Accord Ni deposit
  1. Barberton
  2. Mbombela Local Municipality
  3. Ehlanzeni District Municipality
  4. Mpumalanga
  5. South Africa

-25.6731°, 31.1695°

26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Yellowish green
Cleavage
Very Good

Pronounced, (001)

Density
3.123 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 15°
Refractive index
1.637 – 1.647
Surface relief
Moderate
Principal indices
nα 1.637 · nβ 1.647 · nγ 1.647
Pleochroism
Weak

Faint. X = yellow green, Z = apple green

Dispersion
r > v or r < v
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.320(1) Å · b = 9.214(3) Å · c = 14.302(3) Å
Cell angles
β = 97.10(2) °
Ratio a:b:c
1 : 1.732 : 2.688
Unit cell volume
695.74 ų
Z
2
Type-locality form

Irregular veins in willemseite.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
28NiNickelNickel658.693352.158
29.94%
8OOxygenOxygen1815.999287.982
24.48%
13AlAluminiumAluminium1026.982269.820
22.94%
12MgMagnesiumMagnesium624.305145.830
12.40%
14SiSiliconSilicon428.085112.340
9.55%
1HHydrogenHydrogen81.0088.064
0.69%
Total1176.194100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Fe
  • Cr
  • Mn
  • Co
  • Ca
  • H2O

Synonyms

  • Schuchardite

In other languages

French
Nimite
German
Nimit
Italian
Nimite

Classification

Strunz
10th ed.

9.EC.55

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.55NimiteSpecies
Dana
8th ed.

71.04.01.05

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.04Sheets of 6-membered rings interlayered 1:1, 2:1, and octahedraType
  • 71.04.01Chlorite group (Tri-Dioctahedral)Group
  • 71.04.01.05NimiteSpecies
CIM

16.25.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.25Aluminosilicates of NiGroup
  • 16.25.2NimiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1968Hiemstra, S.A., De Waal, S.A. (1968) Nickel minerals from Barberton, II. Nimite, a nickelian chlorite. National Institute of Metallurgy (South Africa) Research Report, 344, 1-10.
  2. 1969Fleischer, Michael (1969) New Mineral Names. American Mineralogist, 54 (11-12) 1737-1742
  3. 1970de Waal, S. A. (1970) Nickel minerals from Barberton, South Africa: II. Nimite, a nickel-rich chlorite. American Mineralogist, 55 (1-2) 18-30
  4. 2001(2001) Nimite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2011Lazarenkov, V. G., Talovina, I. V., Vorontsova, N. I., Mezentseva, O. P., Ryzhkova, S. O. (2011) Nickel chlorites in the oxide-silicate nickel deposits of the Urals. Lithology and Mineral Resources, 46 (4) 312-320 doi:10.1134/s0024490211030072DOI: 10.1134/s0024490211030072
