Osarizawaite

Pb(Al2Cu2+)(SO4)2(OH)6
IMA status
  • Approved
IMA symbol
Orz
Discovered
1961
Also known as
  • Osarizawaiet

Where it forms, where it's found

Geological setting

Oxidized zone of lead-zinc-copper veins.

Oxidation zone of Pb-Zn-Cu deposits.

Type locality
Osarizawa Mine
  1. Kazuno City
  2. Akita Prefecture
  3. Japan

40.1833°, 140.7500°

66recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Greenish yellow
Streak
Greenish yellow
Tenacity
brittle
Density
3.89 g/cm³

Optical

Optical type
Uniaxial (+) · 2V measured = 15°
Refractive index
1.712 – 1.732
Surface relief
High
Principal indices
nω 1.712 · nε 1.732
Pleochroism
Visible

O = dark yellow E = pale yellowish

Notes

May be biaxial

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 7.05 Å · c = 17.24(1) Å
Z
3
Type-locality form

Earthy and friable masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
36.19%
82PbLeadLead1207.200207.200
33.48%
16SSulfurSulfur232.06064.120
10.36%
29CuCopperCopper163.54663.546
10.27%
13AlAluminiumAluminium226.98253.964
8.72%
1HHydrogenHydrogen61.0086.048
0.98%
Total618.864100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Osarizawaiet

In other languages

French
osarizawaite
German
Osarizawait
Spanish
Osarizawaíta
Italian
Osarizawaite
Japanese
尾去沢石
Arabic
أوساريزاويت

Classification

Strunz
10th ed.

7.BC.10

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BCWith medium-sized and large cationsGroup
  • 7.BC.10OsarizawaiteSpecies
Dana
8th ed.

30.02.04.04

  • 30Anhydrous Sulfates Containing Hydroxyl or HalogenClass
  • 30.02(AB)2(XO4)ZqType
  • 30.02.04Alunite Group (Alunite Subgroup)Group
  • 30.02.04.04OsarizawaiteSpecies
CIM

25.7.9

  • 25SulphatesClass
  • 25.7Sulphates of PbGroup
  • 25.7.9OsarizawaiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1961TAGUCHI, YASURO (1961) On osarizawaite, a new mineral of the alunite group, from the Osarizawa mine, Japan. Mineralogical Journal, 3 (4). 181-194 doi:10.2465/minerj1953.3.181 DOI: 10.2465/minerj1953.3.181
  2. 1962Morris, R. C. (1962) Osarizawaite from Western Australia. American Mineralogist, 47 (9-10) 1079-1093
  3. 1962Fleischer, Michael; Mandarino, J. A.; Servos, Kurt; Toulmin, Priestley, III (1962) New Mineral Names. American Mineralogist, 47 (9-10). 1216-1223
  4. 1963Morris, K. C. (1963) Osarizawaite from Western Australia--a correction. American Mineralogist, 48 (7-8) 947
  5. 1977Cortelezzi C.R. (1977) Occurrence of osarizawaite in Argentina. Neues Jahrbuch für Mineralogie - Monatshefte: 1: 39-44.
