Stolzite

Pb(WO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sz
Discovered
1845
Also known as
  • Bleischeelat
  • Bleiwolframat
  • Lead tungstate
  • +6 more

Where it forms, where it's found

Geological setting

Oxidation zone of hydrothermal tungsten-bearing lead deposits.

Type locality
Zinnwald-Cínovec mining region
  1. Ore Mountains
  2. Europe
164recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Reddish brown · brown · yellowish gray · smoky-gray · gray-brown · ostraw-yellow · lemon-yellow · orange-yellow · red or green (rare)
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

Imperfect on (001); indistinct on (011)

Fracture
Irregular/Uneven · Conchoidal
Density
8.34 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.18 – 2.27
Surface relief
Very high
Principal indices
nω 2.27 · nε 2.18 – 2.19
UV response
May be bright red to red-orange (LW UV), and lemon-yellow (SW UV).
Michel-Lévy diagramhighlighted lineδ = 0.0850
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]850 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation850 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#136
Cell parameters
a = 5.461 Å · c = 12.049 Å
Z
4
Morphology

Crystals commonly dipyramidal (111), (101) or other pyramidal forms; also thick tabular (001), (101), with (011), (112), (001). Development may be complex with over 30 additional forms recorded. Prism faces horizontally striated; pyramidal faces often striated parallel to the edge {h0l}{hhl} or diagonally striated parallel to the edges with third-order pyramids.

Comment

Space group determined on synthetic material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
45.54%
74WTungstenTungsten1183.840183.840
40.40%
8OOxygenOxygen415.99963.996
14.06%
Total455.036100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mo

Synonyms

  • Bleischeelat
  • Bleiwolframat
  • Lead tungstate
  • Scheel-Bleispath
  • Scheelbleispat
  • Scheelsaures Blei
  • Scheeltine
  • Tungstate of Lead
  • Wolframbleierz

In other languages

French
stolzite
German
Scheelbleierz · Stolzit · Wolframbleierz
Spanish
Stolzita
Italian
Stolzite
Portuguese
Stolzita · stolzite
Russian
Вольфрамат свинца · Штольцит

Classification

Strunz
10th ed.

7.GA.05

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GAWithout additional anions or H2OGroup
  • 7.GA.05StolziteSpecies
Dana
8th ed.

48.01.03.02

  • 48Anhydrous Molybdates and TungstatesClass
  • 48.01AXO4Type
  • 48.01.03Wulfenite SeriesGroup
  • 48.01.03.02StolziteSpecies
CIM

27.4.8

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.4TungstatesGroup
  • 27.4.8StolziteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
9 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1820Breithaupt, A. (1820) Kurze Charakteristik des Mineralsystems. 8vo, Freiberg: 14 (as Scheel-Bleispath).
  2. 1832Beudant, François-Sulpice (1832) Traité élémentaire de minéralogie. Deuxiéme Edition [Elementary Treatise on Mineralogy. Second Edition] (2nd ed.) Vol. 2 - Tome II [Volume II]. Chez Verdière.
  3. 1845Haidinger, W. (1845) Zweite Klasse: Geogenide. II. Ordnung. Baryte. VII. Bleibaryt. Stolzit.. in Handbuch der Bestimmenden Mineralogie, Bei Braumüller and Seidel (Wien), 499-506. (as stolzit)
  4. 1858Greg, Robert Philips, Lettsom, William G. (1858) Manual of the Mineralogy of Great Britain and Ireland. John Van Voorst, London.
  5. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
