Pyroxmangite

Mn2+SiO3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pxm
Also known as
  • Pyroxmangiet
  • Sobralit
  • Sobralita
  • +1 more

Where it forms, where it's found

127recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pink · red · brown
Cleavage
Perfect

On (110), (110), (110) ^ (11_0) = 92° perfect; on (010), (001) poor.

Density
3.61 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 37 – 46° · 2V calc = 40 – 42°
Refractive index
1.728 – 1.758
Surface relief
High
Principal indices
nα 1.728 – 1.748 · nβ 1.730 – 1.742 · nγ 1.746 – 1.758
Dispersion
r > v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.690 Å · b = 10.505 Å · c = 17.391 Å
Cell angles
α = 112.17 ° · β = 102.85 ° · γ = 82.93 °
Ratio a:b:c
1 : 1.084 : 1.795
Z
14
Morphology

Crystals commonly tabular on (001); porphyroblastic; granular massive.

Twinning

On (010) lamellar; on (001) simple, uncommon.

Comment

Non-standard cell setting. Reduced cell is: a = 6.721, b = 7.603, c = 16.064 Å, α = 92.62, β = 96.43, γ = 94.13° (calculated from non-standard cell given by Narita et al., 1977). Reduced cell of sample structurally characterised by Pertlik (2000): a = 6.716, b = 7.603, c = 15.919 Å, α = 91.92, β = 96.13, γ = 94.70°.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese154.93854.938
41.93%
8OOxygenOxygen315.99947.997
36.63%
14SiSiliconSilicon128.08528.085
21.44%
Total131.020100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • Ca
  • Na
  • K
  • H2O

Synonyms

  • Pyroxmangiet
  • Sobralit
  • Sobralita
  • Sobralite

In other languages

French
Pyroxmangite
German
Pyroxmangit
Spanish
Piroxmangita
Italian
Piroxmangite · Pyroxmangite
Portuguese
Piroxmangita
Japanese
パイロクスマンガン石
Russian
Пироксмангит

Classification

Strunz
10th ed.

9.DO.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DOInosilicates with 7-, 8-, 10-, 12- and 14-periodic chainsGroup
  • 9.DO.05PyroxmangiteSpecies
Dana
8th ed.

65.06.01.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.06Single-Width Unbranched Chains, W=1 with chains P=7Type
  • 65.06.01Pyroxmangite groupGroup
  • 65.06.01.01PyroxmangiteSpecies
CIM

14.18.35

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.35PyroxmangiteSpecies

Group, growth & confusion

Often grow together
8 minerals
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1913Ford W E, Bradley W M (1913) Pyroxmangite, a new member of the pyroxene group and its alteration product, skemmatite. American Journal of Science 186, 169-174.
  2. 1914Ford, W. E.; Bradley, W. M. (1914) Pyroxmangit, ein neues Glied der Pyroxengruppe, und sein Zersetzungsprodukt: Skemmatit. Zeitschrift für Kristallographie, 53 (1-6). 225-230 doi:10.1524/zkri.1914.53.1.225DOI: 10.1524/zkri.1914.53.1.225
  3. 1936Henderson, E. P.; Glass, Jewell J. (1936) Pyroxmangite, new locality: Identity of sobralite and pyroxmangite. American Mineralogist, 21 (5). 273-294
  4. 1959Liebau, F. (1959) Über die Kristallstruktur des Pyroxmangits (Mn,Fe,Ca,Mg)SiO3. Acta Crystallographica, 12 (3) 177-181 doi:10.1107/s0365110x59000536DOI: 10.1107/s0365110x59000536
  5. 1962Liebau, F., Hilmer, W., Lindemann, G. (1962) Über die Kristallstruktur des Pyroxmangits (Mn,Fe,Ca,Mg)SiO3 und des Rhondonits (Mn,Ca)SiO3. Acta Crystallographica, 15 (6) 622 doi:10.1107/s0365110x62001668DOI: 10.1107/s0365110x62001668
