Rappoldite

PbCo2(AsO4)2 · 2H2O
IMA status
  • Approved
IMA symbol
Rap
IMA approved
1998
Also known as
  • IMA1998-015
  • Rappoldiet

Where it forms, where it's found

Geological setting

Found on dumps.

Type locality
Rappold Mine
  1. Neustädtel
  2. Schneeberg
  3. Erzgebirgskreis
  4. Saxony
  5. Germany

50.5813°, 12.6299°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Light brown to brown-red
Streak
Pale brown-yellow
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
5.28 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85° · 2V calc = 80°
Refractive index
1.85 – 1.9
Surface relief
Very high
Principal indices
nα 1.85 · nβ 1.87 · nγ 1.90
Dispersion
r > v distinct
Extinction
X ~ || c; Y ~ || <mi>[_120]</mi>.
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 11.190(2) Å · b = 10.548(2) Å · c = 7.593(1) Å
Cell angles
α = 100.38(1) ° · β = 109.59(2) ° · γ = 98.96(1) °
Ratio a:b:c
1 : 0.943 : 0.679
Z
4
Morphology

Type material: prismatic or tabular, showing forms (210) and (001).

Twinning

By reflection on (230).

Type-locality form

Rosette-like aggregates of prismatic to tabular crystals to 2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
32.43%
8OOxygenOxygen1015.999159.990
25.04%
33AsArsenicArsenic274.922149.844
23.45%
27CoCobaltCobalt258.933117.866
18.45%
1HHydrogenHydrogen41.0084.032
0.63%
Total638.932100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-015
  • Rappoldiet

In other languages

German
IMA 1998-015 · Rappoldit
Italian
Rappoldite

Classification

Strunz
10th ed.

8.CG.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.20RappolditeSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2000Effenberger, H., Krause, W., Bernhardt, H.-J., Martin, M. (2000) On the symmetry of tsumcorite group minerals based on the new species rappoldite and zincgartrellite. Mineralogical Magazine, 64 (6). 1109-1126 doi:10.1180/002646100549922 DOI: 10.1180/002646100549922
  2. 2001Jambor, J.L., Roberts, A.C. (2001) New mineral names. American Mineralogist: 86: 939-942.
  3. 2001Mandarino, Joseph A. (2001) New minerals. The Canadian Mineralogist, 39 (5) 1473-1502 doi:10.2113/gscanmin.39.5.1473 DOI: 10.2113/gscanmin.39.5.1473
  4. 2005Lapis (2005): 30(7/8): 69.
  5. 2017Hazen, Robert M., Hystad, Grethe, Golden, Joshua J., Hummer, Daniel R., Liu, Chao, Downs, Robert T., Morrison, Shaunna M., Ralph, Jolyon, Grew, Edward S. (2017) Cobalt mineral ecology. American Mineralogist, 102 (1) 108-116 doi:10.2138/am-2017-5798DOI: 10.2138/am-2017-5798
