Rittmannite

(Mn2+,Ca)Mn2+(Fe2+,Mn2+,Mg)2(Al,Fe3+)2(PO4)4(OH)2 · 8H2O
IMA status
  • Approved
IMA symbol
Rit
IMA approved
1987
Also known as
  • IMA1987-048
  • Rittmanniet

Where it forms, where it's found

Type locality
Cubos-Mesquitela-Mangualde area
  1. Mangualde (Mesquitela e Cunha Alta)
  2. Mangualde
  3. Viseu
  4. Portugal

40.5875°, -7.7647°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Very pale yellow to lemon-yellow · brownish yellow.
Streak
white
Cleavage
Poor/Indistinct

(001), indistinct

Density
2.81 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 43° · 2V calc = 52°
Refractive index
1.622 – 1.654
Surface relief
Moderate
Principal indices
nα 1.622 · nβ 1.626 · nγ 1.654
Dispersion
r > v to r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0320
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]320 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation320 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 15.01(4) Å · b = 6.89(3) Å · c = 10.16(3) Å
Cell angles
β = 112.82(25) °
Ratio a:b:c
1 : 0.459 : 0.677
Z
2

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
36.37%
26FeIronIron455.845223.380
19.53%
25MnManganeseManganese454.938219.752
19.21%
15PPhosphorusPhosphorus430.974123.896
10.83%
13AlAluminiumAluminium226.98253.964
4.72%
12MgMagnesiumMagnesium224.30548.610
4.25%
20CaCalciumCalcium140.07840.078
3.50%
1HHydrogenHydrogen181.00818.144
1.59%
Total1143.798100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg

Synonyms

  • IMA1987-048
  • Rittmanniet

In other languages

German
IMA1987-048 · Rittmannit
Italian
IMA1987-048 · rittmannite
Portuguese
IMA1987-048 · Rittmannita

Classification

Strunz
10th ed.

8.DH.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.15RittmanniteSpecies
Dana
8th ed.

42.11.03.04

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.03Whiteite GroupGroup
  • 42.11.03.04RittmanniteSpecies
CIM

19.12.63

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.63RittmanniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1989Marzoni Fecia di Cossato, F., Orlandi, A. (1989) Rittmannite, a new mineral species of the whiteite group from the Mangualde granitic pegmatite, Portugal. The Canadian Mineralogist: 27(3): 447-449. https://rruff.info/doclib/cm/vol27/CM27_447.pdf
  2. 1990Jambor, John L., Grew, Edward S. (1990) New Mineral Names. American Mineralogist, 75 (7-8) 931-937
  3. 2005(2005) Rittmannite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2007Roth P (2007) Rittmannite. in Minerals first discovered in Switzerland and minerals named after Swiss individuals, Kristallografik Verlag (Achberg Germany) 196-197
  5. 2018Birch, William D. (2018) Minerals in the arrojadite, alluaudite and jahnsite–whiteite groups from the Mount Wills pegmatite field, Victoria, Australia. European Journal of Mineralogy, 30 (3) 635-645 doi:10.1127/ejm/2018/0030-2729DOI: 10.1127/ejm/2018/0030-2729
