Whiteite-(MnMnMg)

Mn2+Mn2+Mg2Al2(PO4)4(OH)2 · 8H2O
IMA status
  • Approved
IMA symbol
Wt-MnMnMg
IMA approved
2016
Also known as
  • IMA2015-092
  • Whiteiet-(MnMnMg)

Where it forms, where it's found

Type locality
Iron Monarch Main Pit
  1. Iron Knob
  2. Pastoral Unincorporated Area
  3. South Australia
  4. Australia

-32.7447°, 137.1395°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
reddish orange
Streak
pale orange
Tenacity
brittle
Cleavage
Distinct/Good

parallel to (001)

Fracture
Irregular/Uneven
Density
2.61 g/cm³

Optical

Optical type
Uniaxial (-) · 2V calc = 74.5°
Refractive index
1.582 – 1.613
Surface relief
Moderate
Principal indices
nα 1.582 · nβ 1.586 · nγ 1.613
Pleochroism
Non-pleochroic
Notes

Uniaxial is incompatible with RIs given.

Michel-Lévy diagramhighlighted lineδ = 0.0310
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]310 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation310 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 15.036(2) Å · b = 6.9408(5) Å · c = 9.9431(9) Å
Cell angles
β = 110.827(8) °
Ratio a:b:c
1 : 0.462 : 0.661
Z
2
Type-locality form

single unterminated prismatic crystal

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
53.99%
15PPhosphorusPhosphorus430.974123.896
16.08%
25MnManganeseManganese254.938109.876
14.26%
13AlAluminiumAluminium226.98253.964
7.00%
12MgMagnesiumMagnesium224.30548.610
6.31%
1HHydrogenHydrogen181.00818.144
2.36%
Total770.464100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2015-092
  • Whiteiet-(MnMnMg)

In other languages

German
IMA 2015-092 · Whiteit-(MnMnMg)
Italian
Whiteite- · Whiteite-(MnMnMg)

Classification

Strunz
10th ed.

8.DH.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.15Whiteite-(MnMnMg)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 2012Baijot, M., Hatert, F., Philippo, S. (2012) Mineralogy and geochemistry of phosphates and silicates in the Sapucaia pegmatite, Minas Gerais, Brazil: Genetic implications. The Canadian Mineralogist, 50 (6) 1531-1554 doi:10.3749/canmin.50.6.1531DOI: 10.3749/canmin.50.6.1531
  2. 2014Baijot, Maxime, Hatert, Frédéric, Dal Bo, Fabrice, Philippo, Simon (2014) Mineralogy and petrography of phosphate mineral association from the Jocão pegmatite, Minas Gerais, Brazil. The Canadian Mineralogist, 52 (2) 373-397 doi:10.3749/canmin.52.2.373DOI: 10.3749/canmin.52.2.373
  3. 2016Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2016) New minerals and nomenclature modifications approved in 2015 and 2016, CNMNC Newsletter No 29. Mineralogical Magazine, 80 (1) 199-205 doi:10.1180/minmag.2016.080.080DOI: 10.1180/minmag.2016.080.080
  4. 2019Elliott, Peter, Willis, Anthony C. (2019) Whiteite-(MnMnMg), a new jahnsite-group mineral from Iron Monarch, South Australia: description and crystal structure. The Canadian Mineralogist, 57 (2) 215-223 doi:10.3749/canmin.1800070 DOI: 10.3749/canmin.1800070
  5. 2021(2021) Whiteite-(MnMnMg). Handbook of Mineralogy. Mineralogical Society of America
