Montebrasite

LiAl(PO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mbs
Discovered
1870
Also known as
  • Montebrasiet

Where it forms, where it's found

Geological setting

Granite pegmatite

A late primary mineral in zoned, complex granitic pegmatites.

Type locality
Montebras Mines
  1. Montebras
  2. Soumans
  3. Aubusson
  4. Creuse
  5. Nouvelle-Aquitaine
  6. France

46.3214°, 2.2967°

221recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · colorless · gray white · very pale brown · pale pink · pale yellow

May be colored by inclusions

Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (100), good on (110), distinct on (011), and on (001), imperfect.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
2.98 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 66 – 101° · 2V calc = 52 – 88°
Refractive index
1.594 – 1.645
Surface relief
Moderate
Principal indices
nα 1.594 – 1.615 · nβ 1.608 – 1.624 · nγ 1.616 – 1.645
Birefringence
0.026
Pleochroism
Non-pleochroic
Dispersion
r < v
UV response
May have a faint to medium cream yellow fluorescence in SW and LW, frequently patchy. May have associated fluorescent species affecting the appearance.
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 6.713(1) Å · b = 7.708(1) Å · c = 7.0194(7) Å
Cell angles
α = 91.31(1) ° · β = 117.93(1) ° · γ = 91.77(1) °
Ratio a:b:c
1 : 1.148 : 1.046
Z
4
Morphology

Crude blocky crystals, typically equant to short prismatic [010], with complex form development, to 1.5 meters; also occurs as large cleavable masses; columnar; compact.

Twinning

On (111), common, with composition plane (111) with the resulting twins commonly tabular parallel to (111) and the twinned individuals of about equal size; also tabular (110) and the twinned individuals of very unequal size. Also twins on (111), rare; lamellar. Microscopic polysynthetic twinning is common.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
54.83%
15PPhosphorusPhosphorus130.97430.974
21.23%
13AlAluminiumAluminium126.98226.982
18.49%
3LiLithiumLithium16.9406.940
4.76%
1HHydrogenHydrogen11.0081.008
0.69%
Total145.899100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na

Synonyms

  • Montebrasiet

In other languages

French
Montebrasite
German
Montebrasit
Spanish
Montebrasita
Italian
Montebrasite

Classification

Strunz
10th ed.

8.BB.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BBWith only medium-sized cations, (OH, etc.):RO4 about 1:1Group
  • 8.BB.05MontebrasiteSpecies
Dana
8th ed.

41.05.08.02

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.08Amblygonite GroupGroup
  • 41.05.08.02MontebrasiteSpecies
CIM

19.8.1

  • 19PhosphatesClass
  • 19.8Phosphates of Al and other metalsGroup
  • 19.8.1MontebrasiteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1871Des Cloizeaux, A. (1871) Note sur la montebrasite. Comptes Rendus Hebdomadaires des Séances de l’Académie des Sciences: 73: 306-306 .
  2. 1872Des Cloizeaux, A. (1872) Memoire sur une Novelle Localite D'Amblygonite et sur la Montebrasite, Noveau Phosphate D'Alumine et de Lithine Hydrate. Annales de chimie et de physique, Paris, S. 4 Vol. 27. 385-405
  3. 1879Penfield, S. (1879) On the chemical composition of amblygonite. American Journal of Science: 18: 295-301.
  4. 1910Lacroix, A. (1910) Minéralogie de la France et de ses colonies Vol. 4. Library Polytechnique, Paris.
  5. 1918Backlund (1918) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 40: 757.
