Rossite

Ca(VO3)2 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rs
Discovered
1926
Also known as
  • Rossiet

Where it forms, where it's found

Geological setting

Carnotite-bearing sandstone.

Type locality
Arrowhead Tunnel
  1. Bull Pen Canyon
  2. San Miguel County
  3. Colorado
  4. USA
32recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pale yellow · yellow in transmitted light.
Tenacity
brittle
Cleavage
Distinct/Good

One direction, prominent.

Density
2.45 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 90°
Refractive index
1.71 – 1.84
Surface relief
High
Principal indices
nα 1.71 · nβ 1.77 · nγ 1.84
Dispersion
relatively strong
Extinction
Y ∧ b ≃ 45°; Z ≃ c.
Notes

Optical class is based on recrystallized material.

Michel-Lévy diagramhighlighted lineδ = 0.1300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1300 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1300 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 8.552 Å · b = 8.576 Å · c = 7.028 Å
Cell angles
α = 101.5 ° · β = 114.96 ° · γ = 103.39 °
Ratio a:b:c
1 : 1.003 : 0.822
Z
2
Morphology

Small glassy lumps surrounded by alteration rims. Artificial crystals commonly elongated [001] and rather flattened on (010); rarely tabular (001), lath-like or acicular [001].

Twinning

On (100) ?

Type-locality form

Veinlets; small glassy lumps surrounded by alteration rims of metarossite.

Comment

Space group is based on recrystallized material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
51.61%
23VVanadiumVanadium250.942101.884
32.86%
20CaCalciumCalcium140.07840.078
12.93%
1HHydrogenHydrogen81.0088.064
2.60%
Total310.016100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Rossiet

In other languages

German
Rossit
Italian
Rossite

Classification

Strunz
10th ed.

4.HD.05

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HDInovanadatesGroup
  • 4.HD.05RossiteSpecies
Dana
8th ed.

47.01.01.01

  • 47Vanadium OxysaltsClass
  • 47.01Normal Anhydrous Vanadium OxysaltsType
  • 47.01.01Rossite GroupGroup
  • 47.01.01.01RossiteSpecies
CIM

21.2.2

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.2Vanadates of Mg, Ca, Sr or BaGroup
  • 21.2.2RossiteSpecies

Group, growth & confusion

Often grow together
6 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1928Foshag, W.F., Hess, F.L. (1928) Rossite and metarossite; two new vanadates from Colorado. Proceedings of the U.S. National Museum: 72: 1-12.
  2. 1928Foshag, W.F. (1928) New mineral names. American Mineralogist: 13: 158-160.
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1963Ahmed, F. R.; Barnes, W. H. (1963) The crystal structure of rossite. The Canadian Mineralogist, 7 (5). 713-726
  5. 1985Bayliss, Peter (1985) Powder X-ray diffraction data of rossite. Mineralogical Magazine, 49 (350) 140-141 doi:10.1180/minmag.1985.049.350.24 DOI: 10.1180/minmag.1985.049.350.24
