Sarkinite

Mn2+2(AsO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Srk
Discovered
1885
Also known as
  • Chondrarsenit
  • Chondrarsenita
  • Chondrarsenite
  • +7 more

Where it forms, where it's found

Geological setting

Metamorphosed Fe–Mn orebody.

Type locality
Harstigen Mine
  1. Pajsberg
  2. Persberg ore district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.7853°, 14.3139°

37recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Red · rose-red · reddish-yellow · yellow · pinkish · light rose or yellow in transmitted light
Streak
Red to yellow
Cleavage
Distinct/Good

On (100) distinct.

Fracture
Irregular/Uneven · Conchoidal
Density
4.08 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 83° · 2V calc = 40°
Refractive index
1.793 – 1.809
Surface relief
Very high
Principal indices
nα 1.793 · nβ 1.807 · nγ 1.809
Pleochroism
Weak

Absorption: X > Z > Y.

Dispersion
r > v or r < v
Extinction
Y = b; X ∧ c = –54°.
Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 12.7795(13) Å · b = 13.6127(14) Å · c = 10.2188(11) Å
Cell angles
β = 108.834(2) °
Ratio a:b:c
1 : 1.065 : 0.800
Z
16
Morphology

Crystals commonly thick tabular (100) and somewhat elongated [010]; also occurs as short prismatic [010] crystals, or shortened along this axis and tabular. (100) and (001) are often uneven and (001) is striated [100]. Aggregates into crudely spherical forms at times. Granular.

Comment

For synthetic material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese254.938109.876
41.34%
8OOxygenOxygen515.99979.995
30.09%
33AsArsenicArsenic174.92274.922
28.19%
1HHydrogenHydrogen11.0081.008
0.38%
Total265.801100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chondrarsenit
  • Chondrarsenita
  • Chondrarsenite
  • Chondro-arsenite
  • Chondroarsenit
  • Kondroarsenit
  • Polyarsenit
  • Polyarsenita
  • Polyarsenite
  • Sarkiniet

In other languages

French
sarkinite
German
Sarkinit
Spanish
sarkinite
Italian
sarkinite

Classification

Strunz
10th ed.

8.BB.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BBWith only medium-sized cations, (OH, etc.):RO4 about 1:1Group
  • 8.BB.15SarkiniteSpecies
Dana
8th ed.

41.06.03.03

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.06A2(XO4)ZqType
  • 41.06.03Wolfeite GroupGroup
  • 41.06.03.03SarkiniteSpecies
CIM

20.8.1

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.1SarkiniteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
2 minerals
Commonly confused with
6 minerals

Literature, links & citation

Citations
  1. 1865Igelström, L. J. (1865) Kondroarsenit, ett nytt mineral från Pajsbergs jern-och manganmalmsgrufva i Wermland. Öfversigt af Kongl. vetenskaps-akademiens förhandlingar, 22 (1) 3-4
  2. 1868Dana, James D., Brush, George Jarvis (1868) A System of Mineralogy (5th ed.). p.882
  3. 1884Igelström (1884) Bulletin de la Société française de Minéralogie: 7: 237 (as Xanthoarsénite).
  4. 1885Igelström (1885) Ak. Stockholm, Öfv.: 42: 257 (as Polyarsenite).
  5. 1885Igelström (1885) Bulletin de la Société française de Minéralogie: 8: 369 (as Polyarsenite).
