Triploidite

Mn2+2(PO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tpd
Discovered
1878
Also known as
  • Triploidiet

Where it forms, where it's found

Geological setting

Granitic pegmatite.

Granitic pegmatites.

Type locality
Fillow Quarry
  1. Branchville
  2. Redding
  3. Fairfield County
  4. Connecticut
  5. USA

41.2678°, -73.4392°

32recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Red-brown · light pink · yellow-brown · light pink to light brown in transmitted light
Streak
White, off-white
Tenacity
brittle
Cleavage
Distinct/Good

On (010), good; on (120), fair; on (110), very poor.

Fracture
Irregular/Uneven
Density
3.70 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.709 – 1.74
Surface relief
High
Principal indices
nα 1.709 – 1.735 · nβ 1.710 – 1.736 · nγ 1.714 – 1.740
Birefringence
0.005
Pleochroism
Weak

Pleochroism faint in thick grains with absorption Z > X, Y.

Dispersion
r > v weak
UV response
Not fluorescent in UV.
Notes

2V moderate.

Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#12
Cell parameters
a = 12.366 Å · b = 13.276 Å · c = 9.943 Å
Cell angles
β = 108.23 °
Ratio a:b:c
1 : 1.074 : 0.804
Morphology

Crystals rarely observed, prismatic [001], with the prism zone striated vertically. Parallel-fibrous to columnar aggregates common; also divergent or randomly oriented; fibrous; granular.

Type-locality form

Crystalline aggregates that are distinctly parallel-fibrous to columnar in some cases, and in others divergent. Also randomly fibrous to nearly compact massive. Occasionally individual prismatic crystals.

Comment

P21/a

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese254.938109.876
49.53%
8OOxygenOxygen515.99979.995
36.06%
15PPhosphorusPhosphorus130.97430.974
13.96%
1HHydrogenHydrogen11.0081.008
0.45%
Total221.853100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Triploidiet

In other languages

German
Triploidit
Spanish
Triploidita
Italian
Triploidite
Japanese
トリプロイド石

Classification

Strunz
10th ed.

8.BB.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BBWith only medium-sized cations, (OH, etc.):RO4 about 1:1Group
  • 8.BB.15TriploiditeSpecies
Dana
8th ed.

41.06.03.02

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.06A2(XO4)ZqType
  • 41.06.03Wolfeite GroupGroup
  • 41.06.03.02TriploiditeSpecies
CIM

19.12.13

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.13TriploiditeSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
4 minerals
Commonly confused with
5 minerals

Literature, links & citation

Citations
  1. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. First Paper. American Journal of Science and Arts: 16: 33-46; 114-123 (42,115, 398).
  2. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  3. 1900Kovář and Slavík (1900) Verh. Geol. Reichsanst. Wien: 50: 347 (Herles analysis).
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1925Müllbauer (1925) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 61: 318.
