Schneebergite

BiCo2(AsO4)2(OH) · H2O
IMA status
  • Approved
IMA symbol
Snb
Discovered
1999
IMA approved
1999
Also known as
  • IMA1999-027
  • Schneebergiet

Where it forms, where it's found

Geological setting

in quartz casts of decomposed cobalt and nickel arsenides

Type locality
Roter Berg mining district
  1. Zschorlau
  2. Erzgebirgskreis
  3. Saxony
  4. Germany

50.5537°, 12.6204°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
beige-white to yellowish brown · brown
Streak
white to pale brown
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
5.28 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 85°
Refractive index
1.93 – 1.98
Surface relief
Very high
Principal indices
nα 1.93 · nβ 1.95 · nγ 1.98
Pleochroism
Weak

Weak to distinct, depending on Fe content. With X = Z = pale yellow, Y = brown.

Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.005 Å · b = 6.211 Å · c = 7.44 Å
Cell angles
β = 115.19 °
Ratio a:b:c
1 : 0.690 : 0.826
Z
2
Morphology

Tabular on (201), also showing (001), (101), (101), (102) and (111).

Type-locality form

tabular to lath-like, or acicular crystals to 0.5 mm in length

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth1208.980208.980
32.67%
8OOxygenOxygen1015.999159.990
25.01%
33AsArsenicArsenic274.922149.844
23.42%
27CoCobaltCobalt258.933117.866
18.43%
1HHydrogenHydrogen31.0083.024
0.47%
Total639.704100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1999-027
  • Schneebergiet

In other languages

German
IMA 1999-027 · Schneebergit
Spanish
Schneebergita
Italian
Schneebergite

Classification

Strunz
10th ed.

8.CG.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.15SchneebergiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2002Krause, Werner, Bernhardt, Heinz-Jürgen, Effenberger, Herta, Witzke, Thomas (2002) Schneebergite and nickelschneebergite from Schneeberg, Saxony, Germany: the first Bi-bearing members of the tsumcorite group. European Journal of Mineralogy, 14 (1) 115-126 doi:10.1127/0935-1221/2002/0014-0115 DOI: 10.1127/0935-1221/2002/0014-0115
  2. 2003American Mineralogist (2003): 88: 253 (absract).
  3. 2020(2020) Schneebergite. Handbook of Mineralogy. Mineralogical Society of America
