Shumwayite

[(UO2)(SO4)(H2O)2]2 · H2O
IMA status
  • Approved
IMA symbol
Smw
IMA approved
2015
Also known as
  • IMA2015-058
  • Shumwayiet

Where it forms, where it's found

Geological setting

secondary (alteration) mineral

Green Lizard mine

Type locality
Giveway-Simplot Mine
  1. Red Canyon Mining District
  2. San Juan County
  3. Utah
  4. USA

37.5525°, -110.2828°

5recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale greenish-yellow
Streak
White
Tenacity
brittle
Cleavage
Perfect

(011)

Fracture
Irregular/Uneven
Density
3.844 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 89.8° · 2V calc = 89.6°
Refractive index
1.581 – 1.595
Surface relief
Moderate
Principal indices
nα 1.581 · nβ 1.588 · nγ 1.595
Pleochroism
Non-pleochroic
Dispersion
strong (sense couldn't be defined due to ambiguous sign)
UV response
bright greenish white (LW & SW) - Only Utah specimens; may be quenched by Fe,Zn contents
Notes

Orientation: X=b, Y≈c, Z≈a

Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 6.7475(1) Å · b = 12.5026(3) Å · c = 16.903(1) Å
Cell angles
β = 90.919(6) °
Ratio a:b:c
1 : 1.853 : 2.505
Unit cell volume
1425.79 ų
Z
4
Morphology

prismatic crystals

Type-locality form

prisms, up to about 0.3 mm, [100] elongation; often in subparallel to random intergrowths

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
57.90%
8OOxygenOxygen1715.999271.983
33.08%
16SSulfurSulfur232.06064.120
7.80%
1HHydrogenHydrogen101.00810.080
1.22%
Total822.241100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2015-058
  • Shumwayiet

In other languages

German
IMA 2015-058 · Shumwayit

Classification

Strunz
10th ed.

7.EA.15

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.EAWithout cationsGroup
  • 7.EA.15ShumwayiteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter No 27. Mineralogical Magazine, 79 (5). 1223-1230 doi:10.1180/minmag.2015.079.5.16DOI: 10.1180/minmag.2015.079.5.16
  2. 2017(2017) Shumwayite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2017Kampf, Anthony R., Plášil, Jakub, Kasatkin, Anatoly V., Marty, Joe, Čejka, Jiří, Lapčák, Ladislav (2017) Shumwayite, [(UO2)(SO4)(H2O)2]2·H2O, a new uranyl sulfate mineral from Red Canyon, San Juan County, Utah, USA. Mineralogical Magazine, 81 (2) 273-285 doi:10.1180/minmag.2016.080.091 DOI: 10.1180/minmag.2016.080.091
  4. 2019Sejkora, Jiří, Čejka, Jiří (2019) New data on uranyl sulphate mineral shumwayite from Jáchymov - a Raman spectroscopy study. Bulletin Mineralogie Petrologie, 27 (2) 411-418
  5. 2025Kornyakov, Ilya V.; Samarkina, Nastasia K.; Izatulina, Alina R.; Krzhizhanovskaya, Maria G.; Krivovichev, Sergey V.; Gurzhiy, Vladislav V. (2025) High-temperature powder versus single-crystal X-ray diffraction studies: which method to choose? Thermal behavior of shumwayite, [(UO2)(SO4)(H2O)2]2·H2O. Journal of Applied Crystallography, 58 (5). 1615-1626 doi:10.1107/s160057672500651xDOI: 10.1107/s160057672500651x
