Synadelphite

Mn2+9(AsO4)2(AsO3)(OH)9 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Syd
Discovered
1884
Also known as
  • Allodelphit
  • Allodelphita
  • Allodelphite
  • +2 more

Where it forms, where it's found

Type locality
Moss mine
  1. Nordmark Odal Field
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8167°, 14.1000°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Colourless (crystal centers) · red to brown (exteriors) · blackish · colourless to pale brown or reddish in transmitted light.
Tenacity
brittle
Cleavage
Imperfect/Fair

On (010), imperfect.

Fracture
Irregular/Uneven · Conchoidal
Density
3.57 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 37 – 40° · 2V calc = 36 – 50°
Refractive index
1.75 – 1.93
Surface relief
Very high
Principal indices
nα 1.75 – 1.87 · nβ 1.751 – 1.88 · nγ 1.761 – 1.93
Pleochroism
Visible

X = Colourless or Light brown Y = Colourless or Brown Z = light brown or Dark red-brown Colours are for the colourless material and the coloured material, respectively.

Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0355
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]355 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation355 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#71
Cell parameters
a = 10.754(11) Å · b = 18.865(17) Å · c = 9.884(14) Å
Ratio a:b:c
1 : 1.754 : 0.919
Z
4
Morphology

Crystals short prismatic [001], with (110) striated [001]. Crystals viewed as seeming individuals are fourlings (the mineral was originally thought to be triclinic-pseudo-orthorhombic).

Twinning

Fourlings twinned by reflection on (100) and (010) of a "pseudo-orthogonal triclinic" lattice (crystal-structure determination however showed orthorhombic symmetry). Massive; reniform crusts.

Comment

Originally thought to be triclinic-pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese954.938494.442
45.60%
8OOxygenOxygen2215.999351.978
32.46%
33AsArsenicArsenic374.922224.766
20.73%
1HHydrogenHydrogen131.00813.104
1.21%
Total1084.290100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Allodelphit
  • Allodelphita
  • Allodelphite
  • Synadelphiet
  • Synadelphita

In other languages

German
Synadelphit
Italian
Synadelphite

Classification

Strunz
10th ed.

8.BE.50

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BEWith only medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.BE.50SynadelphiteSpecies
Dana
8th ed.

43.05.12.01

  • 43Compound Phosphates, Etc.Class
  • 43.05Hydrated Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.05.12Synadelphite GroupGroup
  • 43.05.12.01SynadelphiteSpecies
CIM

20.8.8

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.8SynadelphiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1884Igelström (1884) Ak. Stockholm, Öfv.: 41: 86 (as Aimafibrit).
  2. 1884Sjögren, A. (1884) Kristallografiska studier: X. Synadelphit från Nordmarken. Geologiska Föreningens i Stockholm Förhandlingar, 7, 382-386.
  3. 1884Sjögren, Hj. (1884) Kristallografiska studier: VIII. Allaktit från Nordmarken. Geologiska Föreningen i Stockholm Förhandlingar, 7 (4) 220-236 doi:10.1080/11035898409443537DOI: 10.1080/11035898409443537
  4. 1885Sjögren (1885) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 10: 126, 143.
  5. 1889Hamberg (1889) Geologiska Föeningens I Stockholm Förhandlinger: 11: 222.
