Thometzekite

PbCu2+2(AsO4)2 · 2H2O
IMA status
  • Approved
IMA symbol
Tmz
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-103
  • Thometzekiet

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

22recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy
Transparency
Translucent
Colour
Green · bluish-green · olive-green
Streak
White
Density
5.21 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 70° · 2V calc = 68°
Refractive index
1.85 – 1.92
Surface relief
Very high
Principal indices
nα 1.85 · nβ 1.87 · nγ 1.92
Pleochroism
Non-pleochroic
Dispersion
none
Extinction
Wavy extiction
Michel-Lévy diagramhighlighted lineδ = 0.0700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]700 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation700 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.077 Å · b = 6.3 Å · c = 7.661 Å
Cell angles
β = 116.99 °
Ratio a:b:c
1 : 0.694 : 0.844
Z
2
Type-locality form

Bluish-green to green tabular crystals up to 20 μm long and about 1 μm thick.

Comment

There is some uncertainty about whether this mineral is Tric. P-1 or P1, or Mon. C2/m. The best available data is presented above. A Tric. cell with a = 22.4, b = 22.44, c = 7.62, alpha = 70.2, beta = 70, gamma = 69.2, (no "Z" stated), has also been reported.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
31.97%
8OOxygenOxygen1015.999159.990
24.68%
33AsArsenicArsenic274.922149.844
23.12%
29CuCopperCopper263.546127.092
19.61%
1HHydrogenHydrogen41.0084.032
0.62%
Total648.158100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-103
  • Thometzekiet

In other languages

German
IMA 1982-103 · Thometzekit
Italian
Thometzekite

Classification

Strunz
10th ed.

8.CG.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.15ThometzekiteSpecies
Dana
8th ed.

40.02.09.03

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.02AB2(XO4)2·xH2OType
  • 40.02.09Helmutwinklerite SubgroupGroup
  • 40.02.09.03ThometzekiteSpecies
CIM

20.5.8

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.5Arsenates of Ti and PbGroup
  • 20.5.8ThometzekiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1985Schmetzer, K., Nuber, B., Medenbach, O. (1985) Thometzekite, a new mineral from Tsumeb, Namibia, and symmetry relations in the tsumcorite-helmutwinklerite family. Neues Jahrbuch für Mineralogie - Monatshefte, 1985. 446-452
  2. 1988Jambor, John L.; Bladh, Kenneth W.; Ercit, T. Scott; Grice, Joel D.; Grew, Edward S. (1988) New mineral names. American Mineralogist, 73 (7-8). 927-935
  3. 1998Jambor, John L., Grew, Edward S., Roberts, Andrew C. (1998) New mineral names. American Mineralogist, 83 (11) 1347-1352
  4. 1998Krause, Werner, Belendorff, Klaus, Bernhardt, Heinz-Jürgen, Mccammon, Catherine, Effenberger, Herta, Mikenda, Werner (1998) Crystal chemistry of the tsumcorite-group minerals. New data on ferrilotharmeyerite, tsumcorite, thometzekite, mounanaite, helmutwinklerite, and a redefinition of gartrellite. European Journal of Mineralogy, 10 (2). 179-206 doi:10.1127/ejm/10/2/0179DOI: 10.1127/ejm/10/2/0179
  5. 2004Frost, Ray L., Weier, Matt (2004) Raman and infrared spectroscopy of tsumcorite mineral group. Neues Jahrbuch für Mineralogie - Monatshefte, 2004 (7) 317-336 doi:10.1127/0028-3649/2004/2004-0317DOI: 10.1127/0028-3649/2004/2004-0317
