Uvite

CaMg3(Al5Mg)(Si6O18)(BO3)3(OH)3(OH)
IMA status
  • Approved
IMA symbol
Uvt
Also known as
  • IMA2019-113
  • Uviet
  • Uvite (OH-dominant end-member)

Where it forms, where it's found

Geological setting

holotype (2022 paper's) material: "center of a narrow (2-3 cm wide) vein" comprising aggregates of dark-coloured tourmaline, penetrating magnesite- and dolomite-bearing hydrothermally altered metaserpentinite

Type locality
Facciatoia Quarry
  1. San Piero in Campo
  2. Campo nell'Elba
  3. Livorno Province
  4. Tuscany
  5. Italy

42.7511°, 10.2142°

18recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
brown · green · black · red
Streak
grey
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
3.115 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.64 – 1.66
Surface relief
High
Principal indices
nω 1.660 · nε 1.640
Pleochroism
Visible

O = greenish brown, E = pale yellow, with O > E.

UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.9519(10) Å · c = 7.2222(5) Å
Unit cell volume
1597.3 ų
Z
3
Morphology

Lozenge shaped to stubby prisms.

Type-locality form

euhedral crystals, up to 1 cm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
50.97%
14SiSiliconSilicon628.085168.510
17.32%
13AlAluminiumAluminium526.982134.910
13.86%
12MgMagnesiumMagnesium424.30597.220
9.99%
20CaCalciumCalcium140.07840.078
4.12%
5BBoronBoron310.81032.430
3.33%
1HHydrogenHydrogen41.0084.032
0.41%
Total973.149100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2019-113
  • Uviet
  • Uvite (OH-dominant end-member)

In other languages

French
Uvite
German
IMA 2019-113 · Uvit
Russian
Увит

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05UviteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1977Nelen, Joseph A., Dunn, Pete J., Appleman, Daniel, Norberg, Julie (1977) Uvite, a New (Old) Common Member of the Tourmaline Group and Its Implications for Collectors. The Mineralogical Record, 8 (2) 100-108
  2. 2007Rozhdestvenskaya, I. V., Frank-Kamenetskaya, O. V., Kuznetsova, L. G., Bannova, I. I., Bronzova, Yu. M. (2007) Refinement of the crystal structure of lithium-bearing uvite. Crystallography Reports, 52 (2). 203-207 doi:10.1134/s106377450702006xDOI: 10.1134/s106377450702006x
  3. 2010Williams, P. A., Hatert, F., Pasero, M., Mills, S. (2010) New minerals and nomenclature modifications approved in 2010, CNMNC Newsletter No 2. Mineralogical Magazine, 74 (2) 375-377 doi:10.1180/s0026461x00056036 DOI: 10.1180/s0026461x00056036
  4. 2011Henry, Darell J., Novak, Milan, Hawthorne, Frank C., Ertl, Andreas, Dutrow, Barbara L., Uher, Pavel, Pezzotta, Federico (2011) Nomenclature of the tourmaline-supergroup minerals. American Mineralogist, 96 (5) 895-913 doi:10.2138/am.2011.3636 DOI: 10.2138/am.2011.3636
  5. 2018Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) Newsletter 41. European Journal of Mineralogy, 30. 183-186 doi:10.1127/ejm/2018/0030-2736DOI: 10.1127/ejm/2018/0030-2736
