Vanmeersscheite

U(UO2)3(PO4)2(OH)6 · 4H2O
IMA status
  • Approved
IMA symbol
Vms
Discovered
1981
IMA approved
1981
Also known as
  • IMA1981-009
  • Vanmeersscheiet

Where it forms, where it's found

Geological setting

Altered granite pegmatite

Type locality
Kobokobo pegmatite
  1. Mwenga Territory
  2. South Kivu
  3. DR Congo

-3.1000°, 28.1333°

7recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Transparency
Translucent
Colour
Canary Yellow
Cleavage
Distinct/Good

(010) good, (100) fair.

Density
4.67 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 56° · 2V calc = 54°
Refractive index
1.704 – 1.718
Surface relief
High
Principal indices
nα 1.704 · nβ 1.715 · nγ 1.718
Pleochroism
Weak

Yellow to pale yellow.

Dispersion
r > v weak
UV response
Strongly fluorescent in green in short- and longwave UV light.
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 17.06 Å · b = 16.76 Å · c = 7.023 Å
Ratio a:b:c
1 : 0.982 : 0.412
Z
4
Morphology

Plates elongated on [001], forms noted include (010),(100),(101),(101).

Type-locality form

Yellow plates

Comment

Space Group: P21mn

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium4238.029952.116
67.42%
8OOxygenOxygen2415.999383.976
27.19%
15PPhosphorusPhosphorus230.97461.948
4.39%
1HHydrogenHydrogen141.00814.112
1.00%
Total1412.152100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1981-009
  • Vanmeersscheiet

In other languages

German
IMA 1981-009 · Vanmeersscheit
Italian
Vanmeersscheite

Classification

Strunz
10th ed.

8.EC.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.ECUO2:RO4 = 3:2Group
  • 8.EC.20VanmeersscheiteSpecies
Dana
8th ed.

42.07.14.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.14Vanmeersscheite GroupGroup
  • 42.07.14.01VanmeersscheiteSpecies
CIM

19.11.3

  • 19PhosphatesClass
  • 19.11Phosphates of UGroup
  • 19.11.3VanmeersscheiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1982Piret, Paul, Deliens, Michel (1982) La vanmeersscheite U(UO2)3(PO4)2(OH)6 • 4 H2O et la méta-vanmeersscheite U(UO2)3(PO4)2(OH)6 • 2 H2O, nouveaux minéraux. Bulletin de Minéralogie, 105 (1) 125-128 doi:10.3406/bulmi.1982.7594DOI: 10.3406/bulmi.1982.7594
  2. 1982Fleischer, M., Cabri, L.J., Chao, G.Y., Mandarino, J.A., Pabst, A. (1982) New mineral names. American Mineralogist: 67: 1074-1082.
  3. 2005(2005) Vanmeersscheite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2005Burns, Peter C. (2005) U6+ minerals and inorganic compounds: insights into an expanded structural hierarchy of crystal structures. The Canadian Mineralogist, 43 (6) 1839-1894 doi:10.2113/gscanmin.43.6.1839 DOI: 10.2113/gscanmin.43.6.1839
  5. 2009Frost, Ray L., Čejka, Jiří, Dickfos, Marilla J. (2009) Raman spectroscopic study of the uranyl minerals vanmeersscheite U(OH)4[(UO2)3(PO4)2(OH)2]·4H2O and arsenouranylite Ca(UO2)[(UO2)3(AsO4)2(OH)2]·(OH)2·6H2O. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 71 (5) 1799-1803 doi:10.1016/j.saa.2008.06.041DOI: 10.1016/j.saa.2008.06.041
