Arsenohauchecornite

Ni18Bi3AsS16
IMA status
  • Approved
IMA symbol
Ahau
Discovered
1980
Also known as
  • Arsenohauchecorniet
  • Arsenohauchecornitt
  • IMA1978-E

Where it forms, where it's found

Geological setting

Hydrothermal Ni-Co-Cu veins.

Type locality
Vermilion Mine
  1. Denison Township
  2. Greater Sudbury
  3. Ontario
  4. Canada

46.4156°, -81.3614°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Bronze
Fracture
Conchoidal
Density
6.35 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(41.6, 43.0) 470, (46.2, 47.1) 546, (48.2, 49.2) 589, (50.8, 51.6) 650
Reflected-light panel
46.7 %anisotropic · dual curve
Specimen sRGB 248, 167, 86
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Tetragonal
Cell parameters
a = 10.2711(2) Å · c = 10.8070(4) Å
Z
2
Morphology

Tabular crystals to 20 mm.

Type-locality form

Irregular masses up to 10 mm in diameter, occasionally as tabular crystals up to 2x20 mm embedded in chalcopyrite, and rarely as subhedral crystals exhibiting crystal faces several millimeters across.

Comment

Point Group: 4/m 2/m 2/m, 422, _42m, or 4mm.: Space Group: I4/mmm, I422, I_4m2, I_42m, or I4mm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
28NiNickelNickel1858.6931056.474
46.51%
83BiBismuthBismuth3208.980626.940
27.60%
16SSulfurSulfur1632.060512.960
22.59%
33AsArsenicArsenic174.92274.922
3.30%
Total2271.296100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Co
  • Sb

Synonyms

  • Arsenohauchecorniet
  • Arsenohauchecornitt
  • IMA1978-E

In other languages

German
Arsenohauchecornit
Italian
Arsenohauchecornite
Chinese
硫砷铋镍矿

Classification

Strunz
10th ed.

2.BB.10

  • 2Sulfides and SulfosaltsClass
  • 2.BMetal Sulfides, M: S > 1: 1 (mainly 2: 1)Division
  • 2.BBWith NiGroup
  • 2.BB.10ArsenohauchecorniteSpecies
Dana
8th ed.

03.02.05.04

  • 03SulfosaltsClass
  • 03.02ø = 4Type
  • 03.02.05Hauchecornite Group, Complex Ni sulfides (Tetragonal: P4/nnn or I4/mmm)Group
  • 03.02.05.04ArsenohauchecorniteSpecies
CIM

5.8.11

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.8Sulpharsenites etc. of Mn, Fe, Co and NiGroup
  • 5.8.11ArsenohauchecorniteSpecies

Group, growth & confusion

In the same group
6 members
Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1972Gait, R. L., Harris, D. C. (1972) Hauchecornite - antimonian, arsenian and tellurian varieties. The Canadian Mineralogist, 11 (4) 819-825
  2. 1980Gait, Robert I., Harris, Donald C. (1980) Arsenohauchecornite and tellurohauchecornite: new minerals in the hauchecornite group. Mineralogical Magazine, 43 (331) 877-878 doi:10.1180/minmag.1980.043.331.09 DOI: 10.1180/minmag.1980.043.331.09
  3. 1981Fleischer, Michael, Pabst, Adolf (1981) New Mineral Names. American Mineralogist, 66 (3-4) 436-439
  4. 1989Grice, Joel D., Ferguson, R. B. (1989) The crystal structure of arsenohauchecornite. The Canadian Mineralogist, 27 (1) 137-142
  5. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
