Atencioite

Ca2Fe2+3Mg2Be4(PO4)6(OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Aco
IMA approved
2004
Also known as
  • Atencioiet
  • Atencioitt
  • IMA2004-041

Where it forms, where it's found

Type locality
Linópolis
  1. Divino das Laranjeiras
  2. Minas Gerais
  3. Brazil

-18.7284°, -41.4885°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
greenish brown
Tenacity
fragile
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.86 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 85°
Refractive index
1.613 – 1.626
Surface relief
Moderate
Principal indices
nα 1.613 · nβ 1.620 · nγ 1.626
Pleochroism
Visible

brown, coloring dark, greenish-brown

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.668(1) Å · b = 9.879(1) Å · c = 9.883(1) Å
Cell angles
α = 73.53(1) ° · β = 85.60(1) ° · γ = 86.93(1) °
Ratio a:b:c
1 : 1.482 : 1.482
Z
1
Type-locality form

subparallel aggregates of poorly formed crystals up to 3 mm long, greenish brown, and also spheroidal aggregates with a diameter up to 8 mm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
50.45%
15PPhosphorusPhosphorus630.974185.844
17.23%
26FeIronIron355.845167.535
15.54%
20CaCalciumCalcium240.07880.156
7.43%
12MgMagnesiumMagnesium224.30548.610
4.51%
4BeBerylliumBeryllium49.01236.048
3.34%
1HHydrogenHydrogen161.00816.128
1.50%
Total1078.287100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Atencioiet
  • Atencioitt
  • IMA2004-041

In other languages

German
Atencioit · IMA 2004-041
Italian
atencioite
Portuguese
Atencioíta
Chinese
水磷铁铍镁石
Arabic
أتينسيوايت

Classification

Strunz
10th ed.

8.DA.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.10AtencioiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2006Chukanov, N. V., Rastsvetaeva, R. K., Möckel, St., Zadov, A. E., Levitskaya, L. A. (2006) The roscherite group and its new representative member atencioite, Ca2Fe2+□Mg2Fe2+2Be4(PO4)6(OH)4·6H2O. New Data on Minerals, 41. 18-25
