Footemineite

Ca2Mn2+5Be4(PO4)6(OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Ftm
IMA approved
2006
Also known as
  • Footemineiet
  • IMA2006-029
  • Roscherite-1A
  • +1 more

Where it forms, where it's found

Geological setting

Quartz-microcline-spodumene pegmatite

Type locality
Foote Lithium Co. Mine
  1. Kings Mountain
  2. Cleveland County
  3. North Carolina
  4. USA

35.2111°, -81.3556°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Good on (011) and (100)

Density
2.873 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 080° · 2V calc = 089.6°
Refractive index
1.62 – 1.634
Surface relief
Moderate
Principal indices
nα 01.620 · nβ 01.627 · nγ 1.634
Pleochroism
Visible

β (brownish yellow) > α = γ (yellow).

Dispersion
weak r > v or r < v
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 6.742 Å · b = 9.883 Å · c = 9.981 Å
Cell angles
α = 74.12 ° · β = 86.1 ° · γ = 87.36 °
Ratio a:b:c
1 : 1.466 : 1.480
Morphology

Prismatic to bladed generally rough to barrel-shaped crystals

Twinning

Twinning is simple, by reflection, with twin boundaries across the length of the crystals.

Type-locality form

Prismatic to bladed generally rough to barrel-shaped crystals up to about 1.5 mm long and 1 mm in diameter

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
47.85%
25MnManganeseManganese554.938274.690
24.16%
15PPhosphorusPhosphorus630.974185.844
16.35%
20CaCalciumCalcium240.07880.156
7.05%
4BeBerylliumBeryllium49.01236.048
3.17%
1HHydrogenHydrogen161.00816.128
1.42%
Total1136.832100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Footemineiet
  • IMA2006-029
  • Roscherite-1A
  • Triclinic Roscherite

In other languages

French
footemineite
German
Footemineit · IMA 2006-029
Italian
footemineite

Classification

Strunz
10th ed.

8.DA.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.10FootemineiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1975Fanfani, L., Nunzi, A., Zanazzi, P. F., Zanzari, A. R. (1975) The crystal structure of Roscherite. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 22 (3). 266-277 doi:10.1007/bf01087845DOI: 10.1007/bf01087845
  2. 2007Rastsvetaeva, R. K., Chukanov, N. V., Verin, I. A., Atencio, D. (2007) The crystal structure of footemineite. Doklady Earth Sciences, 416 (1) 1053-1056 doi:10.1134/s1028334x07070161DOI: 10.1134/s1028334x07070161
  3. 2008Atencio, D., Matioli, P. A., Smith, J. B., Chukanov, N. V., Coutinho, J. M.V., Rastsvetaeva, R. K., Mockel, S. (2008) Footemineite, the Mn-analog of atencioite, from the Foote mine, Kings Mountain, Cleveland County, North Carolina, U.S.A., and its relationship with other roscherite-group minerals. American Mineralogist, 93 (1) 1-6 doi:10.2138/am.2008.2469 DOI: 10.2138/am.2008.2469
  4. 2009Poirier, G., Ercit, T. S., Tait, K. T., Piilonen, P. C., Rowe, R. (2009) New Mineral Names. American Mineralogist, 94 (2) 399-408 doi:10.2138/am.2009.538DOI: 10.2138/am.2009.538
  5. 2021(2021) Footemineite. Handbook of Mineralogy. Mineralogical Society of America
