Zanazziite

Ca2Be4Mg5(PO4)6(OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Zan
Discovered
1986
IMA approved
1986
Also known as
  • IMA1986-054
  • Zanazziiet

Where it forms, where it's found

Geological setting

Granite pegmatite

Granitic pegmatites

Type locality
Ilha claim
  1. Taquaral
  2. Itinga
  3. Minas Gerais
  4. Brazil

-16.6453°, -41.8637°

16recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Pearly
Transparency
Translucent
Colour
Pale to dark olive-green
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Good on (100) Distinct on (010)

Density
2.76 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 72° · 2V calc = 66°
Refractive index
1.606 – 1.62
Surface relief
Moderate
Principal indices
nα 1.606 · nβ 1.61 · nγ 1.62
Dispersion
r < v
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 15.874(4) Å · b = 11.854(3) Å · c = 6.605(1) Å
Cell angles
β = 95.35 °
Ratio a:b:c
1 : 0.747 : 0.416
Unit cell volume
1237 ų
Z
2
Morphology

Barrel-shaped pseudohexagonal crystals. Forms observed: (100), {11O}and (001).

Type-locality form

As barrel-shaped crystals and crystal rosettes up to 4 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
55.30%
15PPhosphorusPhosphorus630.974185.844
18.89%
12MgMagnesiumMagnesium524.305121.525
12.35%
20CaCalciumCalcium240.07880.156
8.15%
4BeBerylliumBeryllium49.01236.048
3.67%
1HHydrogenHydrogen161.00816.128
1.64%
Total983.667100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Si

Synonyms

  • IMA1986-054
  • Zanazziiet

In other languages

German
IMA 1986-054 · Zanazziit
Spanish
Zanazziíta
Italian
Zanazziite
Chinese
水磷铍镁石

Classification

Strunz
10th ed.

8.DA.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.10ZanazziiteSpecies
Dana
8th ed.

42.07.07.03

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.07Roscherite groupGroup
  • 42.07.07.03ZanazziiteSpecies
CIM

19.12.64

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.64ZanazziiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1990Leavens, Peter B., White, John Sampson, Nelen, Joseph A. (1990) Zanazziite, a new mineral from Minas Gerais, Brazil. The Mineralogical Record, 21 (5) Tucson. 413-417
  2. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  3. 2005(2005) Zanazziite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2009Rastsvetaeva, R. K., Rozenberg, K. A., Chukanov, N. V., Möckel, S. (2009) The crystal structure of an iron-rich variety of zanazziite belonging to heteropolyhedral framework roscherite-group beryllophosphates. Crystallography Reports, 54 (4) 568-571 doi:10.1134/s1063774509040051DOI: 10.1134/s1063774509040051
  5. 2013Frost, Ray L., Xi, Yunfei, Scholz, Ricardo, Belotti, Fernanda M., Dias Menezes Filho, Luiz Alberto (2013) A vibrational spectroscopic study of the phosphate mineral zanazziite – Ca2(MgFe2+)(MgFe2+Al)4Be4(PO4)6⋅6(H2O) Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 104. 250-256 doi:10.1016/j.saa.2012.11.017DOI: 10.1016/j.saa.2012.11.017
