Greifensteinite

Ca2Be4Fe2+5(PO4)6(OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Gfs
IMA approved
2001
Also known as
  • Greifensteiniet
  • IMA2001-044

Where it forms, where it's found

Geological setting

Li-rich granite pegmatite.

Type locality
Greifensteine
  1. Ehrenfriedersdorf
  2. Erzgebirgskreis
  3. Saxony
  4. Germany

50.6486°, 12.9311°

30recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dark olive-green
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Good on (100)

Fracture
Irregular/Uneven
Density
2.93 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80° · 2V calc = 64°
Refractive index
1.624 – 1.638
Surface relief
Moderate
Principal indices
nα 1.624 · nβ 1.634 · nγ 1.638
Pleochroism
Visible

X = light bluish green, Y = light green, Z = brownish green

Notes

X = b

Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 15.903(7) Å · b = 11.885(7) Å · c = 6.677(3) Å
Cell angles
β = 94.68(4) °
Ratio a:b:c
1 : 0.747 : 0.420
Z
2
Type-locality form

Olive green radiated aggregates up to 5 mm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
47.66%
26FeIronIron555.845279.225
24.47%
15PPhosphorusPhosphorus630.974185.844
16.28%
20CaCalciumCalcium240.07880.156
7.02%
4BeBerylliumBeryllium49.01236.048
3.16%
1HHydrogenHydrogen161.00816.128
1.41%
Total1141.367100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Greifensteiniet
  • IMA2001-044

In other languages

German
Greifensteinit · IMA 2001-044
Italian
Greifensteinite

Classification

Strunz
10th ed.

8.DA.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.10GreifensteiniteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 2002Chukanov, N.V., Möckel, S., Rastsvetaeva, R.K., Zadov, A.E. (2002) Greifensteinite Ca2Be4(Fe2+,Mn)5(PO4)6(OH)4·6H2O — a new mineral from Greifenstein, Saxony. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva: 131(4): 47-52.
  2. 2002Rastsvetaeva, R.K., Gurbanova, O.A., Chukanov, N.V. (2002) Crystal structure of greifensteinite Ca2Be4(Fe2+,Mn)5(PO4)6(OH)4·6H2O. Doklady Chemistry: 383: 78-81.
  3. 2003Grew, E.S., Pertsev, N.N., Roberts, A.C. (2003) New mineral names. American Mineralogist: 88: 1175-1180.
  4. 2003Chukanov, Nikita V.; Möckel, Steffen; Raszvetaeva, Ramiza K.; Zadov, Aleksandr E. (2003) Greifensteinit aus Sachsen, Österreich, Cornwall, USA, Brasilien und Kasachstan [Greifensteinite from Saxony, Austria, Cornwall, USA, Brazil and Kazakhstan]. Lapis, 28 (4). 39
  5. 2004Mandarino, Joseph A. (2004) New minerals. The Canadian Mineralogist, 42 (1) 215-234 doi:10.2113/gscanmin.42.1.215 DOI: 10.2113/gscanmin.42.1.215
