Saléeite

Mg(UO2)2(PO4)2(H2O)10
IMA status
  • Approved
  • Grandfathered
IMA symbol
Slé
Discovered
1932
Also known as
  • Saléeiet
  • Saléite

Where it forms, where it's found

Geological setting

Oxidation zone of polymetallic uranium-bearing hydrothermal deposits and sedimentary uranium deposits.

Type locality
Shinkolobwe Mine
  1. Shinkolobwe
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0486°, 26.5508°

88recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous (Glassy)
Transparency
Transparent · Translucent · Opaque
Colour
Lemon-yellow · straw-yellow · greenish yellow
Streak
Yellow-white
Tenacity
brittle
Cleavage
Perfect

[001] Perfect, [010] Indistinct, [110] Indistinct

Fracture
Micaceous
Density
3.27 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 61°
Refractive index
1.544 – 1.585
Surface relief
Moderate
Principal indices
nα 1.554 – 1.559 · nβ 1.570 – 1.582 · nγ 1.571 – 1.585 · nω 1.571 – 1.585 · nε 1.544 – 1.565
Birefringence
0.017
Pleochroism
Visible

X = Colourless Z = Pale greenish yellow

Luminescence
Fluorescent
UV response
Bright lemon-yellow (LW UV); pale yellow (SW UV).
Notes

Typically nearly uniaxial -, sectored.

Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.951(1) Å · b = 19.942(1) Å · c = 6.967(1) Å
Cell angles
β = 90.58(1) °
Ratio a:b:c
1 : 2.869 : 1.002
Z
2
Morphology

Saleeite is pseudotetragonal, the last few water molecules distort the structure. Forms square plates, composite, flattened on (001), and exhibiting (001), (100), (120), and (012). Subparallel lamellar aggregates common.

Epitaxy

Oriented growths on Torbernite with parallel axes.

Comment

P21/n; originally given cell: a = 6.951, b = 19.947, c = 9.896 Å, β = 135.17°. The structure consists of UO2PO4 sheets between which are located Mg2+ ions and water molecules. The Mg2+ ions are octahedrally coordinated to 6 of the 10 interlayer waters, but the last 4 water molecules are not bound to Mg.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
50.94%
8OOxygenOxygen2215.999351.978
37.67%
15PPhosphorusPhosphorus230.97461.948
6.63%
12MgMagnesiumMagnesium124.30524.305
2.60%
1HHydrogenHydrogen201.00820.160
2.16%
Total934.449100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Saléeiet
  • Saléite

In other languages

French
Saléeite
German
Saléeit
Spanish
Saléeita
Italian
Saléeite

Classification

Strunz
10th ed.

8.EB.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.05SaléeiteSpecies
Dana
8th ed.

40.2a.11.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.11— unnamed intermediate level —Group
  • 40.2a.11.01SaléeiteSpecies
CIM

19.11.12

  • 19PhosphatesClass
  • 19.11Phosphates of UGroup
  • 19.11.12SaléeiteSpecies

Group, growth & confusion

Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1932Thoreau, J.; Vaes, J.-F. (1932) La saléeite, nouveau minéral uranifère. Bulletin de la Société Belge de Géologie de Paléontologie & d'Hydrologie, 42. 96-100
  2. 1934Foshag, W.F. (1934) New mineral names. American Mineralogist, 19, 35-36.
  3. 1939Schoep (1939) Med. Kl. Wetens. Kon. Vlaam. Ac.: 65.
  4. 1950Mrose, Mary E. (1950) Studies on uranium minerals (III): Saléeite from Schneeberg, Saxon. American Mineralogist, 35 (7-8) 525-530
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
