Coesite

SiO2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Coe
Discovered
1954

Where it forms, where it's found

Geological setting

In sandstone associated with a meteor impact crater (under and nearby).

Formed at pressures > 20 kbar. Impact craters, kimberlites, eclogites.

Type locality
Meteor Crater
  1. Meteor Crater area
  2. Coconino County
  3. Arizona
  4. USA

35.0281°, -111.0225°

77recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5 – 8/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Colourless · very pale pink · very pale yellowish-white
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

Suspected on (010)(012)

Fracture
Sub-Conchoidal
Density
2.92 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 54 – 64°
Refractive index
1.593 – 1.604
Surface relief
Moderate
Principal indices
nα 1.593 – 1.599 · nγ 1.597 – 1.604
Birefringence
0.004
Pleochroism
Non-pleochroic
Dispersion
r < v weak
UV response
Not fluorescent in UV
Notes

On synthetic material

Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 7.143(2) Å · b = 12.383(3) Å · c = 7.143(2) Å
Cell angles
β = 120 °
Ratio a:b:c
1 : 1.734 : 1.000
Z
16
Morphology

Irregular to rectangular grains.

Type-locality form

Irregular grains from 5-50 microns in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen215.99931.998
53.26%
14SiSiliconSilicon128.08528.085
46.74%
Total60.083100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Na

In other languages

French
13778-38-6 · Coésite
German
Coesit
Spanish
Coesita
Italian
Coesite
Japanese
コーサイト · コース石
Chinese
單斜石英 · 柯氏石英 · 柯石英
Russian
Коесит · Коэсит

Classification

Strunz
10th ed.

4.DA.35

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DAWith small cations: Silica familyGroup
  • 4.DA.35CoesiteSpecies
Dana
8th ed.

75.01.04.01

  • 75Tectosilicates Si Tetrahedral FrameworksClass
  • 75.01Si Tetrahedral Frameworks - SiO2 with [4] coordinated SiType
  • 75.01.04— unnamed intermediate level —Group
  • 75.01.04.01CoesiteSpecies
CIM

7.8.2

  • 7Oxides and HydroxidesClass
  • 7.8Oxides of SiGroup
  • 7.8.2CoesiteSpecies

Group, growth & confusion

Commonly confused with
7 minerals

Literature, links & citation

Citations
  1. Potočny, T., Kośmińska, K., Majka, J. (2023): Crystallographic EBSD-based characterization of palisade quartz-coesite inclusions (Dora Maira, Western Alps). 9th Meeting of the Mineralogical Society of Poland / 28th Meeting of the Petrology group of the Mineralogical Society of Poland, "Oceanic lithosphere: rocks, minerals, and critical resources", October 19-22, Bielawa, Poland. Mineralogia - Special Papers, 51, 91.
  2. 1954SOSMAN, R. B. (1954) New High-Pressure Phases of Silica. Science, 119 (3099). 738-739 doi:10.1126/science.119.3099.738DOI: 10.1126/science.119.3099.738
  3. 1955Ramsdell, Lewis S. (1955) The crystallography of "coesite". American Mineralogist, 40 (11-12) 975-982
  4. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (11-12). 1313-1317
  5. 1960Chao, E. C. T., Shoemaker, E. M., Madsen, B. M. (1960) First Natural Occurrence of Coesite. Science, 132 (3421). 220-222 doi:10.1126/science.132.3421.220DOI: 10.1126/science.132.3421.220
