Tridymite

SiO2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Trd
Also known as
  • Alpha-Tridymite
  • Asmanit
  • Asmanita
  • +8 more

Where it forms, where it's found

Geological setting

Vapor phase deposition in vesicles and lithophysae, phenocrysts in volcanic rocks, contact metamorphosed sandstones.

Type locality
Cerro San Cristóbal
  1. Pachuca Municipality
  2. Hidalgo
  3. Mexico
466recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Colourless · white · yellowish white · or grey
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

[0001] Indistinct, [1010] Imperfect

Fracture
Conchoidal
Density
2.25 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40 – 86° · 2V calc = 50 – 72°
Refractive index
1.468 – 1.486
Surface relief
Low
Principal indices
nα 1.468 – 1.482 · nβ 1.47 – 1.484 · nγ 1.474 – 1.486
Dispersion
none
Luminescence
Non-fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 9.932(5) Å · b = 17.216(6) Å · c = 81.854(9) Å
Cell angles
α = 90 ° · β = 90 ° · γ = 90 °
Ratio a:b:c
1 : 1.733 : 8.241
Z
320
Morphology

Pseudohexagonal plates, wedge-shaped, tabular.

Twinning

Trilling, multiple contact twins or simple twins on (1016) and contact or penetration twins on (3034)

Comment

Orthorhombic, pseudohexagonal; triclinic below 100°C

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen215.99931.998
53.26%
14SiSiliconSilicon128.08528.085
46.74%
Total60.083100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Alpha-Tridymite
  • Asmanit
  • Asmanita
  • Asmanite
  • Low tridymite
  • Tridymita
  • Tridymite-alpha
  • Tridymite-α
  • α-Tridymit
  • α-Tridymita
  • α-Tridymite

In other languages

French
15468-32-3 · Alpha-tridymite · Asmanite · Christensenite · Tridymite
German
Asmanit · Tridymit
Spanish
Asmanita · Tridimita
Italian
Tridimite
Portuguese
tridimita · Tridimite
Japanese
トリディマイト · りん珪石 · 鱗珪石 · 鱗石英
Chinese
鱗石英
Russian
Асманит · Тридимит
Arabic
تريديميت

Classification

Strunz
10th ed.

4.DA.10

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DAWith small cations: Silica familyGroup
  • 4.DA.10TridymiteSpecies
Dana
8th ed.

75.01.02.01

  • 75Tectosilicates Si Tetrahedral FrameworksClass
  • 75.01Si Tetrahedral Frameworks - SiO2 with [4] coordinated SiType
  • 75.01.02— unnamed intermediate level —Group
  • 75.01.02.01TridymiteSpecies
CIM

7.8.3

  • 7Oxides and HydroxidesClass
  • 7.8Oxides of SiGroup
  • 7.8.3TridymiteSpecies

Group, growth & confusion

Often grow together
4 minerals
Commonly confused with
7 minerals

Literature, links & citation

Citations
  1. Mitchell, R. S. & Tufts, S. 1973. Wood opal - a tridymite-like mineral. Amer. Min., 58, 717-20.
  2. Lakdawalla, Emily (December 18, 2015). "Curiosity stories from AGU: The fortuitous find of a puzzling mineral on Mars, and a gap in Gale's history". The Planetary Society. Retrieved December 21, 2015.
  3. 1868vom Rath, G. (1868) Vorläufige Mitteilung über eine neue Kristallform der Kieselsäure (Tridymit). Annalen der Physik und Chemie: 209: 507.
  4. 1868vom Rath, G. (1868) Über den Tridymit eine neue krystallisierte Modification der Kieselsäure. Annalen der Physik und Chemie: 211: 437.
  5. 1868Poggend. (1868) Ann. Physical Chemistry: 133: 508.
