Diaphorite

Ag3Pb2Sb3S8
IMA status
  • Approved
  • Grandfathered
IMA symbol
Dpr
Discovered
1871
Also known as
  • Bleisilberantimonit
  • Brongniardite
  • Diaphoriet
  • +5 more

Where it forms, where it's found

Geological setting

Hydrothermal veins formed at moderate temperatures.

Type locality
Příbram District
  1. Central Bohemian Region
  2. Czech Republic

49.6883°, 14.0092°

136recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Steel grey to black
Tenacity
brittle
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
6.04 g/cm³

Optical

Optical colour
White to greyish white
Anisotropism
Strong
Internal reflections
None
Tropism
Anisotropic
Reflectance R%
(38.2,40.1) 400, (37.8,39.8) 420, (37.5,39.5) 440, (37.3,39.3) 460, (37.0,39.0) 480, (36.7,38.8) 500, (36.4,38.6) 520, (36.0,38.3) 540, (35.6,38.0) 560, (35.3,37.8) 580, (35.0,37.4) 600, (34.8,37.2) 620, (34.5,37.0) 640, (34.2,36.6) 660, (33.8,36.1) 680, (33.4,35.8) 700
UV response
none
Reflected-light panel
35.8 %anisotropic · dual curve
Specimen sRGB 211, 150, 85
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong
Reflected colour
White to greyish white
Internal reflections
None

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 15.849(4) Å · b = 17.914(4) Å · c = 5.901(1) Å
Cell angles
β = 116.425(3) °
Ratio a:b:c
1 : 1.130 : 0.372
Z
4
Morphology

Prismatic [001]. Often striated [001]. Sometimes highly complex crystals.

Twinning

On (120); on (241).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
30.48%
51SbAntimonyAntimony3121.760365.280
26.86%
47AgSilverSilver3107.868323.604
23.80%
16SSulfurSulfur832.060256.480
18.86%
Total1359.764100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Cu

Synonyms

  • Bleisilberantimonit
  • Brongniardite
  • Diaphoriet
  • Diaphorita
  • Diaphorite (of Zepharovich)
  • Ultrabasit (von Rosický and Štěrba-Böhm)
  • Ultrabasita
  • Ultrabasite (of Rosický and Štěrba-Böhm)

In other languages

German
Bleisilberantimonit · Diaphorit
Spanish
Diaforita
Italian
Diaforite

Classification

Strunz
10th ed.

2.JB.05

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.05DiaphoriteSpecies
Dana
8th ed.

03.05.04.01

  • 03SulfosaltsClass
  • 03.052.5 < ø < 3Type
  • 03.05.04— unnamed intermediate level —Group
  • 03.05.04.01DiaphoriteSpecies
CIM

5.7.30

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.30DiaphoriteSpecies

Group, growth & confusion

Often grow together
7 minerals

Literature, links & citation

Citations
  1. 1871Zepharovich, M. V. R. (1871): Über Diaphorit und Freieslebenit. Sitzungsberichte der Kaiserlichen Akademie der Wissenschaften, Mathematisch-Naturwissenschaftliche Classe, 1. Abt., 63, 130-156.
  2. 1938Palache, Charles (1938) Crystallographic studies of the sulphosalts: baumhauerite, meneghinite, jordanite, diaphorite, freieslebenite. American Mineralogist, 23 (11) 821-836
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1958HELLNER, ERWIN (1958) Über komplex zusammengesetzte Spießglanze III. Zur Struktur des Diaphorits, Ag3Pb2Sb3S8. Zeitschrift für Kristallographie, 110 (1-6) 169 doi:10.1524/zkri.1958.110.16.169 DOI: 10.1524/zkri.1958.110.16.169
  5. 1977Hoffman, V., Trdlička, Z., Hulinský, V., Langrová, A., Arnoldová, V. (1977): Mineralogisch-chemisches Studium des Diaphorits von Kutná Hora (ČSSR). Chemie der Erde, 36, 36-44.
