Fabrièsite

Na3Al3Si3O12 · 2H2O
IMA status
  • Approved
IMA symbol
Fab
IMA approved
2012
Also known as
  • Fabrièsiet
  • IMA2012-080

Where it forms, where it's found

Geological setting

Late-stage metamorphic veins of a jadeite deposit. Intergrown with nepheline and trinepheline.

Type locality
Tawmaw (Tawhmaw
  1. Taw Maw)
  2. Hpakant-Tawmaw Jade Tract
  3. Hpakant Township (Hpakan
  4. Phakant
  5. Phakan)
  6. Mohnyin District
  7. Kachin State
  8. Myanmar

25.6884°, 96.2548°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White to pale yellow
Streak
White
Density
2.386 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 78°
Refractive index
1.503 – 1.508
Surface relief
Moderate
Principal indices
nα 1.503 · nβ 1.506 · nγ 1.508
Pleochroism
Non-pleochroic
UV response
Not fluorescent in UV
Notes

The optical parameters are for synthetic nepheline hydrate I. The calculated mean refractive index is 1.511.

Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#33
Cell parameters
a = 16.4260 Å · b = 15.0140 Å · c = 5.2235 Å
Ratio a:b:c
1 : 0.914 : 0.318
Type-locality form

Skeletal allotriomorphic crystals up to 15–20 μm long and 5–10 μm wide.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
48.46%
14SiSiliconSilicon328.08584.255
18.23%
13AlAluminiumAluminium326.98280.946
17.52%
11NaSodiumSodium322.99068.970
14.92%
1HHydrogenHydrogen41.0084.032
0.87%
Total462.189100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fabrièsiet
  • IMA2012-080

In other languages

French
fabrièsite
German
Fabrièsit · IMA 2012-080
Italian
fabriesite · IMA2012-080

Classification

Strunz
10th ed.

9.GB.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GBChains of single connected 4-membered ringsGroup
  • 9.GB.05FabrièsiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) IMA Commission on New Minerals, Nomenclature and Classification. CNMNC Newsletter No. 15. Mineralogical Magazine, 77 (1) 1-12 doi:10.1180/minmag.2013.077.1.01DOI: 10.1180/minmag.2013.077.1.01
  2. 2014Ferraris, Cristiano, Parodi, Gian Carlo, Pont, Sylvain, Rondeau, Benjamin, Lorand, Jean-Pierre (2014) Trinepheline and fabriesite: two new mineral species from the jadeite deposit of Tawmaw (Myanmar) European Journal of Mineralogy, 26 (2) 257-265 doi:10.1127/0935-1221/2014/0026-2348DOI: 10.1127/0935-1221/2014/0026-2348
  3. 2015(2015) Fabrièsite. Handbook of Mineralogy. Mineralogical Society of America
