Fluorannite

KFe2+3(Si3Al)O10F2
IMA status
  • Approved
IMA symbol
Fann
Also known as
  • Fluoranniet
  • IMA1999-048

Where it forms, where it's found

Geological setting

A-type granite.

Type locality
Western suburb
  1. Suzhou City
  2. Suzhou
  3. Jiangsu
  4. China
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Iron-black
Streak
Grey
Tenacity
sectile
Cleavage
Perfect

(0001)

Density
3.16 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.596 – 1.648
Surface relief
Moderate
Principal indices
nα 1.596 · nβ 1.648 · nγ 1.648
Pleochroism
Strong

X = pale brown, Y = dark green, Z = reddish brown.

Dispersion
r < v weak
Extinction
Y = b.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0520
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]520 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation520 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.369(8) Å · b = 9.289(3) Å · c = 10.153(8) Å
Cell angles
β = 100.49(1) °
Ratio a:b:c
1 : 1.730 : 1.891
Z
2
Morphology

Euhedral to subhedral sheets and tabular crystals to more than 6 mm.

Twinning

None observed

Type-locality form

Iron-black euhedral-subhedral tabular-sheet crystals. 2 to 4 mm long and 1 to 3 mm thick.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron355.845167.535
32.48%
8OOxygenOxygen1015.999159.990
31.01%
14SiSiliconSilicon328.08584.255
16.33%
19KPotassiumPotassium139.09839.098
7.58%
9FFluorineFluorine218.99837.996
7.37%
13AlAluminiumAluminium126.98226.982
5.23%
Total515.856100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluoranniet
  • IMA1999-048

In other languages

German
Fluorannit · IMA 1999-048
Italian
Fluorannite

Classification

Strunz
10th ed.

9.EC.20

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.20FluoranniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2000Shen Ganfu, Lu Qi, and Xu Jinsha (2000): Fluorannite: A new mineral of mica group from western suburb of Suzhou City. Acta Petrologica et Mineralogica 19(4), 356-362 (in Chinese with English abstract).
  2. 2001Jambor, J.L., Roberts, A.C. (2001) New mineral names. American Mineralogist, 86. 1534-1537
  3. 2001Mandarino, Joseph A. (2001) New minerals. The Canadian Mineralogist, 39 (5) 1473-1502 doi:10.2113/gscanmin.39.5.1473 DOI: 10.2113/gscanmin.39.5.1473
  4. 2021(2021) Fluorannite. Handbook of Mineralogy. Mineralogical Society of America
