Hsianghualite

Li2Ca3Be3(SiO4)3F2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hsi
Discovered
1958
Also known as
  • Hsianghualiet
  • Hsianghualit

Where it forms, where it's found

Geological setting

Phlogopite veins in metamorphosed Devonian limestone that was intruded by granite.

Type locality
Xianghualing Mine
  1. Xianghualing Sn-polymetallic ore field
  2. Linwu Co.
  3. Chenzhou
  4. Hunan
  5. China

25.4586°, 112.5672°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · colorless
Streak
White
Tenacity
brittle
Cleavage
None Observed
Density
2.97 g/cm³

Optical

Optical type
Isotropic
Surface relief
Moderate
Principal indices
n 1.613
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.613

Crystallography

Crystal system
Isometric
Space group
#215
Cell parameters
a = 12.897(4) Å
Z
8
Morphology

Crystals modifed by the dodecahedron, to 1.5 cm; granular, massive.

Type-locality form

White trisoctahedral or dodecahedral crystals and granular masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
40.39%
20CaCalciumCalcium340.078120.234
25.29%
14SiSiliconSilicon328.08584.255
17.72%
9FFluorineFluorine218.99837.996
7.99%
4BeBerylliumBeryllium39.01227.036
5.69%
3LiLithiumLithium26.94013.880
2.92%
Total475.389100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • Na
  • K

Synonyms

  • Hsianghualiet
  • Hsianghualit

In other languages

French
Hsianghualite
German
Hsianghualith
Italian
hsianghualite
Japanese
香花石

Classification

Strunz
10th ed.

9.GB.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GBChains of single connected 4-membered ringsGroup
  • 9.GB.05HsianghualiteSpecies
Dana
8th ed.

77.01.01.05

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.01Analcime and related speciesGroup
  • 77.01.01.05HsianghualiteSpecies
CIM

17.1.7

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.7HsianghualiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1958Huang W.-H., Tu S., Wang K.-H., Chao C.-L., Yu C.-C. (1958) Hsiang-hua-shih, a new beryllium mineral. Ti-chih-yueh-k'an: 7: 35-35 (in Chinese).
  2. 1959Fleischer, M. (1959) New Mineral Names. American Mineralogist, 44 (11-12). 1321-1329
  3. 1960Beus, A.A. (1960) Geochemistry of beryllium and the genetic types of beryllium deposits. Akad. Nauk SSSR Inst. mineral., geokhim., i kristallokhim redkikh elementov: 1960: l-329. (in Russian)
  4. 1961Fleischer, M. (1961) New mineral names. American Mineralogist, 46 (1-2). 241-244
  5. 1973Section of Crystal Structure Analysis of the Academy of Geological Sciences (1973) The crystal structure of hsianghualite. Acta Geologica Sinica: 47(2): 235-242.
