Limousinite

BaCa[Be4P4O16] · 6H2O
IMA status
  • Approved
IMA symbol
Lms
IMA approved
2019
Also known as
  • IMA2019-011
  • Limousiniet

Where it forms, where it's found

Type locality
Vilatte-Haute Quarry (Alluaud Quarry)
  1. Vilatte Quarries (La Vilate)
  2. Chanteloube
  3. Razès
  4. Bellac
  5. Haute-Vienne
  6. Nouvelle-Aquitaine
  7. France

46.0625°, 1.3672°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent
Colour
Colorless to snow-white
Tenacity
brittle
Cleavage
None Observed

Described as "without cleavage planes".

Density
2.58 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 18°
Refractive index
1.532 – 1.558
Surface relief
Moderate
Principal indices
nα 1.532 · nβ 1.532 · nγ 1.558
Pleochroism
Non-pleochroic
UV response
Non-fluorescent
Notes

non-dispersive

Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 9.4958(4) Å · b = 13.6758(4) Å · c = 13.4696(4) Å
Cell angles
β = 90.398(3) °
Ratio a:b:c
1 : 1.440 : 1.418
Unit cell volume
1757 ų
Z
4
Morphology

Prismatic crystals up to 0.9 mm long with rhombic cross-sections.

Type-locality form

Isolated, partly corroded, colorless to snow-white prismatic crystals up to 0.9 mm long with rhombic cross sections, in vug in altered primary Fe-Mn phosphates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2215.999351.978
50.18%
56BaBariumBarium1137.327137.327
19.58%
15PPhosphorusPhosphorus430.974123.896
17.66%
20CaCalciumCalcium140.07840.078
5.71%
4BeBerylliumBeryllium49.01236.048
5.14%
1HHydrogenHydrogen121.00812.096
1.73%
Total701.423100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2019-011
  • Limousiniet

In other languages

German
IMA 2019-011 · Limousinit
Italian
Limousinite

Classification

Strunz
10th ed.

8.CA.80

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CAWith small and large/medium cationsGroup
  • 8.CA.80LimousiniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2019Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2019) CNMNC Newsletter No 50, New minerals and nomenclature modifications approved in 2019. Mineralogical Magazine, 83 (4) 615-620 doi:10.1180/mgm.2019.46DOI: 10.1180/mgm.2019.46
  2. 2020Hatert, Frédéric, Dal Bo, Fabrice, Bruni, Yannick, Meisser, Nicolas, Vignola, Pietro, Risplendente, Andrea, Châtenet, François-Xavier, Lebocey, Julien (2020) Limousinite, BaCa[Be4P4O16]·6H2O, a new beryllophosphate mineral with a phillipsite-type framework. The Canadian Mineralogist, 58 (6) 815-827 doi:10.3749/canmin.2000007DOI: 10.3749/canmin.2000007
  3. 2022(2022) Limousinite. Handbook of Mineralogy. Mineralogical Society of America
