Lussierite

Na10[(UO2)(SO4)4](SO4)2(H2O)3
IMA status
  • Approved
IMA symbol
Lsi
IMA approved
2018
Also known as
  • IMA2018-101
  • Lussieriet

Where it forms, where it's found

Geological setting

Efflorescent mineral, formed in the humid underground workings of an abandoned mine in a sandstone-hosted uranium deposit.

Type locality
Blue Lizard Mine
  1. Red Canyon Mining District
  2. San Juan County
  3. Utah
  4. USA

37.5572°, -110.2968°

1recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light greenish yellow
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.87 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 88° · 2V calc = 88.4°
Refractive index
1.493 – 1.518
Surface relief
Moderate
Principal indices
nα 1.493 · nβ 1.505 · nγ 1.518
Pleochroism
Visible

X = colourless, Y = Z = green yellow; X < Y ≈ Z.

Dispersion
r > v, moderate
Extinction
X = b; Z ∧ a = 44° in obtuse β.
UV response
Bright cyan under 365 nm ultraviolet light.
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
Cc
Cell parameters
a = 9.3134(4) Å · b = 28.750(1) Å · c = 9.634(7) Å
Cell angles
β = 93.442(7) °
Ratio a:b:c
1 : 3.087 : 1.034
Unit cell volume
2575.1 ų
Z
4
Morphology

Prisms or blades, elongate on [001] and sometimes flattened on (010). The prisms tend to occur in sprays or randomly scattered individuals. Blades tend to occur in parallel growths. Crystals exhibit the prism forms (010), (110) and (110), and have angled, wedgelike terminations composed of a series of {_1k1} forms: (111), (131), (151), (171) and {_1·17·1}.

Twinning

Twinning is not observed visually, but the structure refinement indicates twinning by merohedry.

Type-locality form

Crystals are prisms or blades, up to about 0.5 mm in length. Prisms tend to occur in sprays or randomly scattered individuals. Blades tend to occur in parallel growths.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2915.999463.971
41.05%
92UUraniumUranium1238.029238.029
21.06%
11NaSodiumSodium1022.990229.900
20.34%
16SSulfurSulfur632.060192.360
17.02%
1HHydrogenHydrogen61.0086.048
0.53%
Total1130.308100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2018-101
  • Lussieriet

In other languages

German
IMA 2018-101 · Lussierit

Classification

Strunz
10th ed.

7.EC.75

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.ECWith medium-sized and large cationsGroup
  • 7.EC.75LussieriteSpecies

Group, growth & confusion

Often grow together
8 minerals

Literature, links & citation

Citations
  1. 2018Hålenius, Ulf, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) NEWSLETTER 46. European Journal of Mineralogy, 30 (6) 1181-1189 doi:10.1127/ejm/2018/0030-2819DOI: 10.1127/ejm/2018/0030-2819
  2. 2019Kampf, Anthony R., Olds, Travis A., Plášil, Jakub, Nash, Barbara P., Marty, Joe (2019) Lussierite, a new sodium uranyl sulfate mineral with bidentate UO7–SO4linkage from the Blue Lizard mine, San Juan County, Utah, USA. Mineralogical Magazine, 83 (6) 799-808 doi:10.1180/mgm.2019.34 DOI: 10.1180/mgm.2019.34
  3. 2022(2022) Lussierite. Handbook of Mineralogy. Mineralogical Society of America
